ABB 1P Pole Isolator Switch - 32A Maximum Current

Se alla Isolator Switches

Antal (1 enhet)*

161,87 kr

(exkl. moms)

202,34 kr

(inkl. moms)

Add to Basket
välj eller skriv kvantitet
I lager
  • 36 enhet(er) är redo att levereras
Behöver du mer? Ange den kvantitet du behöver och klicka på "Kontrollera leveransdatum"
Enheter
Per enhet
1 +161,87 kr

*vägledande pris

RS-artikelnummer:
175-5079
Tillv. art.nr:
2CDD281101R0032 SD201/32
Tillverkare / varumärke:
ABB
Hitta liknande produkter genom att välja ett eller flera attribut.
Välj alla

Brand

ABB

Number of Poles

1P

Maximum Current

32A

Voltage Rating

60 V dc, 253V ac

Accepts Padlocks

Yes

Normal State Configuration

NO

Series

SD201

Range

Pro M Compact

Auxiliary Contacts Available

Yes

Length

17.5mm

Width

69mm

Depth

88mm

Maximum Operating Temperature

+55°C

Throw Configuration

SPST

Terminal Type

Screw

Minimum Operating Temperature

-25°C

The SD 200 extends the proven System pro M compact ® series by a new range of switch disconnectors which provides state-of-the-art safety and comfort. The series is available with 1 to 4 poles with rated currents from 16 to 63 A and provides disconnection properties. With a rated voltage of 253/440 V AC, a rated conditional short-circuit current of 25 kA, terminals with protection from misconnection, a “Real CPI” contact position indication, as well as full compatibility with all MCB accessories, SD 200 is unique in its field of application.

Clear contact position indication in red/green (“Real CPI”)
Highest performance at an increased voltage level
35 mm² cylinder lift terminal with 2 terminal openings
Consistent design to other System pro M DIN rail products
Cross wiring with MCBs or RCDs using busbars PS
Durable device identification due to laser labeling
Captive screws with recessed head
