WAGO 788 Series Interface Relay, DIN Rail Mount, 24V ac Coil, DPDT, 8A Load

Se kategorien

Antal (1 enhet)*

176,50 kr

(exkl. moms)

220,62 kr

(inkl. moms)

Add to Basket
välj eller skriv kvantitet
I lager
  • Dessutom levereras 39 enhet(er) från den 22 december 2025
Behöver du mer? Ange den kvantitet du behöver och klicka på "Kontrollera leveransdatum"
Enheter
Per enhet
1 +176,50 kr

*vägledande pris

RS-artikelnummer:
180-3040
Tillv. art.nr:
788-512
Tillverkare / varumärke:
WAGO
Hitta liknande produkter genom att välja ett eller flera attribut.
Välj alla

Brand

WAGO

Coil Voltage

24V ac

Contact Configuration

DPDT

Mounting Type

DIN Rail

Series

788

Load Current Rating

8A

Maximum Input Voltage

24V ac

Load Voltage Rating

250V ac

Terminal Type

Cage Clamp

Switching Voltage

250V ac

Depth

86mm

Height

54mm

Length

15mm

Contact Material

Silver Alloy

Input Current

34mA

Input Voltage Range

Maximum 24V ac

Standards Met

DNV GL TAA00001D1, EN 61010-2-201, EN 61373, EN 61810-1, GL, NK TA17255M, PRS TE/1989/880590/13, UL, UL E175199 Sec.6

Minimum Operating Temperature

-25°C

Operating Temperature Range

-25 → +50°C

Special Features

IP20 Degree of protection, LED Indication

Life

1 x 10^3 (Electrical) cycles, 30 x 10^6 (Mechanical) cycles

Maximum Operating Temperature

+50°C

Dimensions

15 x 54 x 86mm

COO (Country of Origin):
DE
Relay module, Nominal input voltage: 24 VAC, 2 changeover contacts, Limiting continuous current: 8 A, Red status indicator, Module width: 15 mm

Reinforced insulation between coil and contacts
A separator plate (e.g., 209-191) must be used for voltages greater than 250 V between adjacent relay modules and for compliance with the reinforced insulation requirements.
To protect the relay coils and contacts, inductive loads must be dampened with an effective protection circuit.
