Linear Guide Rails

A linear guide rail is a fixed beam cut to length, along which any number of items can move freely using linear movement, depending on the load needed and the configuration of the fixture. The carriage which sits on the linear rail, contains the linear bearings which provide contact points between the two. Linear rails are typically used on doors, machine guarding and seating.

Types of linear guides

Guides with plain motion

Plain bearings are the simplest type of linear guides, with their straightforward construction and easy installation process. There are several types, including boxway and dovetail, both of which can carry high loads.

Guides with rolling motion

Rolling linear guides incorporate balls or rollers between two bearing surfaces. They can be recirculating or non-recirculating: recirculating designs have ongoing motion along the rail and so can continue to roll for an infinite distance, while non-recirculating designs are limited by the length of the bearing.

Types of rails

There are various different types of linear rail, ranging from 'V'-shaped steel rails through to compact shaft raceways and flexible options made from stainless steel and aluminium.


...
Read more Read less

Filter

Visar 1 - 20 av 272 produkter
Resultat per sida
Beskrivning Pris Manufacturer Series Rail Width Rail Length Material Dynamic Load Rating Static Load Rating
RS-artikelnummer 667-1346
Tillv. art.nrWS-16-60-1000
VarumärkeIgus
1 511,09 kr
Each
Enheter
W 54mm 1000mm Hard Anodized Aluminium - 8400N
RS-artikelnummer 849-8739
Tillv. art.nrN1S150300LCNE01 =N/P KPCZ85
VarumärkeNSK
879,60 kr
Each
Enheter
N1S 15mm 300mm Carbon Steel 5750 N@ 100 km 9100N
RS-artikelnummer 667-1330
Tillv. art.nrWS-20-1500
VarumärkeIgus
1 457,66 kr
Each
Enheter
W 27mm 1500mm Hard Anodized Aluminium, Stainless Steel - -
RS-artikelnummer 448-5506
Tillv. art.nrNS-01-80-300
VarumärkeIgus
205,86 kr
Each
Enheter
N 80mm 300mm Anodised Aluminium - 1000N
RS-artikelnummer 409-523
Tillv. art.nrR987261859
VarumärkeBosch Rexroth
3 549,09 kr
Each
Enheter
R1605 28mm 760mm Steel 31700N 41300N
RS-artikelnummer 311-3733
Tillv. art.nrTS-01-20-1000
VarumärkeIgus
919,34 kr
Each
Enheter
T 20mm 1000mm Hard Anodized Aluminium - 7.4kN
RS-artikelnummer 448-5461
Tillv. art.nrNS-01-40-300
VarumärkeIgus
162,70 kr
Each
Enheter
N 40mm 300mm Anodised Aluminium - 700N
RS-artikelnummer 375-2417
Tillv. art.nrNS-01-27-1000
VarumärkeIgus
417,39 kr
Each
Enheter
N 27mm 1000mm Anodised Aluminium - 500N
RS-artikelnummer 409-583
Tillv. art.nrR987261834
VarumärkeBosch Rexroth
843,49 kr
Each
Enheter
R0445 9mm 200mm Steel - -
RS-artikelnummer 667-1336
Tillv. art.nrWS-20-1000
VarumärkeIgus
910,49 kr
Each
Enheter
W 27mm 1000mm Hard Anodized Aluminium, Stainless Steel - -
RS-artikelnummer 488-5243
Tillv. art.nrWS-10-40-1000
VarumärkeIgus
644,21 kr
Each
Enheter
W 40mm 1000mm Hard Anodized Aluminium, Stainless Steel - 4800N
RS-artikelnummer 619-2391
Tillv. art.nrP1U090095SKN-PCT
VarumärkeNSK
276,41 kr
Each
Enheter
PU 9mm 95mm Stainless Steel 1490N 21500N
RS-artikelnummer 409-511
Tillv. art.nrR987261850
VarumärkeBosch Rexroth
3 574,89 kr
Each
Enheter
R1605 23mm 820mm Steel 22800N 30400N
RS-artikelnummer 787-1470
Tillv. art.nrDA0115-0120RC-RS
VarumärkeAccuride
326,60 kr
Each
Enheter
DA0115 40mm - Aluminium - -
RS-artikelnummer 849-8727
Tillv. art.nrN1H251000LCN-PCZ
VarumärkeNSK
2 889,52 kr
Each
Enheter
N1H 25mm 1000mm Carbon Steel 26800 N@ 100 km 46000N
RS-artikelnummer 667-1333
Tillv. art.nrWS-20-600
VarumärkeIgus
567,75 kr
Each
Enheter
W 27mm 600mm Hard Anodized Aluminium, Stainless Steel - -
RS-artikelnummer 619-2492
Tillv. art.nrP1U120800SKN-PCT
VarumärkeNSK
2 337,66 kr
Each
Enheter
PU 12mm 800mm Stainless Steel 2830N 3500N
RS-artikelnummer 448-5433
Tillv. art.nrNS-01-17-300
VarumärkeIgus
119,12 kr
Each
Enheter
N 17mm 300mm Anodised Aluminium - 50N
RS-artikelnummer 409-612
Tillv. art.nrR987261840
VarumärkeBosch Rexroth
4 138,23 kr
Each
Enheter
R1605 15mm 1000mm Steel 7800N 13500N
RS-artikelnummer 488-5057
Tillv. art.nrTS-04-12-600
VarumärkeIgus
623,40 kr
Each
Enheter
T 12mm 600mm Hard Anodized Aluminium - 0.96kN
