Texas Instruments Adjustable Shunt Voltage Reference 2.5 - 36V ±2.0 % 5-Pin SOT-23, TL431BID

Se alla Voltage References
Lagerinformation är för närvarande otillgänglig
RS-artikelnummer:
169-5615
Tillv. art.nr:
TL431BID
Tillverkare / varumärke:
Texas Instruments
Hitta liknande produkter genom att välja ett eller flera attribut.
Välj alla

Brand

Texas Instruments

Nominal Voltage

2.5 - 36V

Package Type

SOT-23

Reference Type

Adjustable

Initial Accuracy

±2.0 %

Mounting Type

Surface Mount

Topology

Shunt

Maximum Output Current

100mA

Maximum Input Voltage

37 V

Minimum Output Voltage

2.5 V

Maximum Output Voltage

36 V

Pin Count

5

Dimensions

2.9 x 1.6 x 1.15mm

Maximum Operating Temperature

+70 °C

Length

2.9mm

Minimum Operating Temperature

0 °C

Width

1.6mm

Height

1.15mm

Shunt Voltage Reference, Adjustable, TL Series



Voltage References, Texas Instruments


Precison Fixed and Adjustable Voltage Reference ICs utilsing series, shunt or series/shunt topologies and available in both through-hole and surface mount packages. Voltage References are available with initial accuracies of ±0.02 to ±2%.
