NKK Switches Toggle Switch, Panel Mount, On-Off-On, DPDT, Solder Terminal, 125V ac

Se alla Toggle Switches
Tillfälligt slut
RS-artikelnummer:
181-3652
Tillv. art.nr:
S7AW
Tillverkare / varumärke:
NKK Switches
Hitta liknande produkter genom att välja ett eller flera attribut.
Välj alla

Brand

NKK Switches

Contact Configuration

DPDT

Switch Operation

On-Off-On

Contact Current Rating

20 A

Mounting Type

Panel Mount

Terminal Type

Solder

IP Rating

IP67

Illuminated

No

Panel Cut Out Diameter

12.5mm

Actuator Length

17.5mm

Voltage Rating

125V ac

Contact Material

Silver Alloy (Movable & Stationary)

Contact Resistance

10mΩ

Standards Met

CSA, UL

Operating Temperature Range

-10 → +70°C

Maximum Operating Temperature

+70°C

Minimum Operating Temperature

-10°C

COO (Country of Origin):
PH
NKK's full line of toggles features both PC board and panel mounting options available with a full array of actuator options and terminations to meet virtually any application. Subminiature and ultra-miniature to dual seal waterproof and high-capacity toggle switches are offered. Matching indicators are available. Designed to perform and withstand extreme environments for critical applications such as construction equipment, transportation, and medical equipment. Our waterproof toggle switch is great for marine applications.

Medium Capacity Standard Size Panel Seal Toggles

5A-50A
Bushing mount or mounting screws.
Available in solder lug, screw lug or quick connect terminals.
