INA HF2520-L564 Sprag Clutch Bearing 25mm I.D., 32mm O.D., 20mm Race Width

RS-artikelnummer:: 137-1793
Tillv. art.nr:: HF2520-L564
Tillverkare / varumärke:: INA

INA HF2520-L564 Sprag Clutch Bearing 25mm I.D., 32mm O.D., 20mm Race Width

Se kategorien

Mängdrabatt möjlig

Antal (1 enhet)*

227,14 kr

(exkl. moms)

283,92 kr

(inkl. moms)

GRATIS leverans för online beställningar över 500,00 kr

I lager

7 enhet(er) är redo att levereras
Plus 21 enhet(er) är redo att levereras från en annan plats

Behöver du mer? Ange den kvantitet du behöver och klicka på "Kontrollera leveransdatum"

Enheter	Per enhet
1 - 4	227,14 kr
5 - 9	217,73 kr
10 - 24	213,47 kr
25 +	208,99 kr

*vägledande pris

RS-artikelnummer:: 137-1793
Tillv. art.nr:: HF2520-L564
Tillverkare / varumärke:: INA

Drawn Cup Roller Clutches

INA from Schaeffler drawn cup roller clutches are one-way clutches comprising thin‑walled, drawn outer rings with a series of ramps on the inside diameter. There are also plastic cages, pressure springs and needle rollers. They can transmit high torques in one direction and are compact in a radial direction.

Drawn cup roller clutches give precise indexing, since the individual spring loading of the needle rollers ensures continuous contact between the shaft, needle rollers and ramps. They allow high indexing frequencies due to their low mass and the resulting low moment of inertia of the clamping elements. They also have a low overrunning frictional torque.

Features and Benefits

• Lower operating costs

• Reduced maintenance due to improved lubrication

• Lower heat generation

• Less noise

• Roller clutches, HF series, do not have a bearing arrangement and can only transmit torques

• Roller clutches, HFL series, have an integral plain or rolling bearing arrangement and can support torques and radial forces.

Product Application Information

Drawn cup roller clutches can be used in various applications such as indexing clutches, back-stopping clutches and overrunning clutches. In these cases, the drawn cup roller clutch performs an overrunning or locking function.

Suffixes

KF - Plastic pressure springs

Schaeffler Series HF Sprag Clutch Bearing, 25mm Inside Diameter, 66Nm Torque - HF2520-L564

This sprag clutch bearing is designed for high-performance applications across various industrial sectors. It features a robust inside diameter of 25mm and an outside diameter of 32mm, making it an essential component for machines requiring reliable overrunning capabilities. With a torque rating of 66 Nm, this bearing can efficiently handle demanding mechanical tasks. It is ideal for applications that demand reliability and efficiency in motion control.

Features & Benefits

• Designed for efficient overrunning with low backlash
• High torque capacity supports demanding loads
• Compact dimensions for limited installation space
• Capable of 5500 rpm for speedy operation

Applications

• Used for automation systems in factories
• Ideal for electronic assemblies requiring precise movements
• Used for machinery for electrical
• Suitable for mechanical systems needing high torque transmission
• Recommended for various industrial clutch solutions

How does the specified overrunning speed benefit operational efficiency?

The high overrunning speed of 5500 rpm allows for quick and responsive operation in machinery, reducing downtime and increasing overall efficiency in production processes. This rapid response is crucial in applications where timing and speed are essential.

What torque handling capabilities does this bearing offer?

It has a torque capacity of 66 Nm, providing the strength required to manage significant loads and ensure the smooth operation of mechanical systems. This robust performance is vital for applications that face high-stress conditions.

Are there specific installation considerations to keep in mind?

Proper alignment during installation is critical to prevent premature wear. Adequate space should be ensured to accommodate the 25 mm bore size, allowing for smooth integration into current systems and maintaining optimal performance.

What advantages do high torque bearings provide in industrial applications?

High torque bearings facilitate the transmission of significant forces with minimal friction, improving mechanical efficiency and enabling machinery to perform more reliably even under heavy loads, thereby enhancing productivity.

What factors determine the lifespan of this mechanical bearing?

The lifespan is influenced by load conditions, environmental factors, and maintenance practices. Regular inspections and appropriate lubrication can significantly extend the service life, ensuring sustained performance in demanding environments.

INA

Hitta liknande produkter genom att välja ett eller flera attribut.

	Välj alla
	Brand INA
	Inside Diameter 25mm
	Outside Diameter 32mm
	Torque 66Nm
	Race Width 20mm
	Series HF
	Over-running Speed 5500rpm
