Aim-TTi PSA1303USC Handheld Spectrum Analyser, 1.3GHz

RS-artikelnummer:: 238-4074
Tillv. art.nr:: PSA1303USC
Tillverkare / varumärke:: Aim-TTi

Antal (1 enhet)*

17 205,55 kr

(exkl. moms)

21 506,94 kr

(inkl. moms)

GRATIS leverans för online beställningar över 500,00 kr

I lager

2 enhet(er) är redo att levereras
Dessutom levereras 2 enhet(er) från den 13 februari 2026

Behöver du mer? Ange den kvantitet du behöver och klicka på "Kontrollera leveransdatum"

Enheter	Per enhet
1 +	17 205,55 kr

*vägledande pris

RS-artikelnummer:: 238-4074
Tillv. art.nr:: PSA1303USC
Tillverkare / varumärke:: Aim-TTi

Specifikationer

Datablad

Lagstiftning och ursprungsland

Produktdetaljer

Hitta liknande produkter genom att välja ett eller flera attribut.

Välj alla	Attribut	Värde
	Brand	Aim-TTi
	Bandwidth	1.3GHz
	Number of Channels	1
	Wave Traces	Live, Reference
	Sweep Modes	Continuous, Single
	Setting Modes	Zero Span
	Series	PSA Series 3
	Maximum Frequency	1.3GHz
	Minimum Frequency	1 MHz
	Frequency Stability	1PPM
	Display Type	TFT
	Screen Size	4.3 in
	Markers	Dual
	RF Input	N Connector
	Interface Type	USB
	Desktop/Handheld	Handheld
	Weight	580g
	Plug Type	Universal
	Height	192mm
	Model Number p	PSA1303USC
	Minimum Operating Temperature	+5°C
	Maximum Operating Temperature	+40°C
	Length	92mm
	Dimensions	192 x 92 x 49 (HxLxW)mm
	Width	49mm
	Battery Life	6 h
	Battery Type	Li-ion

	Välj alla
	Brand Aim-TTi
	Bandwidth 1.3GHz
	Number of Channels 1
	Wave Traces Live, Reference
	Sweep Modes Continuous, Single
	Setting Modes Zero Span
	Series PSA Series 3
	Maximum Frequency 1.3GHz
	Minimum Frequency 1 MHz
	Frequency Stability 1PPM
	Display Type TFT
	Screen Size 4.3 in
	Markers Dual
	RF Input N Connector
	Interface Type USB
	Desktop/Handheld Handheld
	Weight 580g
	Plug Type Universal
	Height 192mm
	Model Number p PSA1303USC
	Minimum Operating Temperature +5°C
	Maximum Operating Temperature +40°C
	Length 92mm
	Dimensions 192 x 92 x 49 (HxLxW)mm
	Width 49mm
	Battery Life 6 h
	Battery Type Li-ion

COO (Country of Origin):: GB

Aim-TTi PSA Series 3 Series Spectrum Analyser, 1.3 GHz Bandwidth, 3 h Battery Life - PSA1303USC

This handheld spectrum analyser by Aim-TTi, the PSA Series 3 - USC, with 1.3 GHz bandwidth, is designed to offer exceptional performance in a compact size. It features a TFT display, RF input via N Connector, and USB interface for connectivity. With a focus on portability and functionality, this spectrum analyser is ideal for various applications in the electronics and automation industries.

Features & Benefits

• Handheld spectrum analyser with 1.3 GHz bandwidth
• Compact design with a 4.3-inch TFT display for easy operation
• RF Input via N Connector for accurate measurements
• USB Interface for data transfer and connectivity
• Lightweight and portable, weighing only 580g
• Battery operation of more than 3 hours for on-the-go use
• Zero Span mode with AM and FM audio demodulation
• Live, view, and reference traces for comprehensive analysis
• Dual markers with smart movement for precise measurements
• Frequency counter with 10Hz resolution for accuracy

Applications

• Interference analysis in radio communication field environments
• Antenna alignment and signal strength mapping
• Covert transmitter detection and spurious emissions evaluation
• EMC frequency evaluations and detection of abnormal frequencies

Can it operate for more than 3 hours on battery?

Yes, it offers a battery life of more than 3 hours for continuous operation.

Will it provide detailed trace and analysis features?

Yes, it includes live, view, and reference traces with smart marker movement for precise measurements.

Is it suitable for interference analysis in radio communication fields?

Yes, it is designed for applications like antenna alignment, signal strength mapping, and spurious emissions detection.
