NKK Switches YB Series Illuminated Push Button Switch, On-On, Panel, 16 mm Cutout, DPDT, IP65, 30 V 250 V

Se alla Push Button Switches
Tillfälligt slut
RS-artikelnummer:
195-9448
Tillv. art.nr:
YB26WCKW01
Tillverkare / varumärke:
NKK Switches
Hitta liknande produkter genom att välja ett eller flera attribut.
Välj alla

Brand

NKK Switches

Product Type

Push Button Switch

Actuator Colour

Black

Switch Operation

On-On

Illuminated

Yes

Panel Cutout Size

16 mm

Series

YB

Mount Type

Panel

Contact Configuration

DPDT

IP Rating

IP65

Minimum Operating Temperature

-25°C

Contact AC Voltage

250V

Contact DC Voltage

30V

Switch Configuration

On-On

Maximum Operating Temperature

50°C

Switch Contact Current

3 A

Standards/Approvals

UL, CSA, RoHS

COO (Country of Origin):
PH
The NKK Switches push button DPDT switch has On-(On) circuit configuration belongs to YB series. Phosphor bronze with tin plating terminals are used for switch as well as for lamp terminals.

It uses spot illumination with incandescent lamps or multi-element LEDs, with or without resistors.

Combination bezel-barrier is an integral part of the switch and prevents accidental actuation.

Distinctive design of snap-action contacts for shock resistance, long life, and sensitive actuation.

High density design to give behind panel depth of less than one inch
