Hitta liknande produkter genom att välja ett eller flera attribut.

Välj alla	Attribut	Värde
	Brand	Renesas Electronics
	Family Name	R8C
	Package Type	LQFP
	Mounting Type	Surface Mount
	Pin Count	52
	Device Core	R8C / Tiny Series CPU
	Data Bus Width	16bit
	Program Memory Size	16 (ROM) kB, 2 (Flash) kB
	Maximum Frequency	20MHz
	RAM Size	1 kB
	USB Channels	0
	Number of PWM Units	0
	Typical Operating Supply Voltage	2.2 → 5.5 V
	Height	1.55mm
	Width	10.1mm
	Dimensions	10.1 x 10.1 x 1.55mm
	Number of ADC Units	1
	Length	10.1mm
	ADCs	1 (12 x 10 bit)
	Maximum Number of Ethernet Channels	0
	Instruction Set Architecture	CISC
	Minimum Operating Temperature	-20 °C
	Program Memory Type	Flash, ROM
	Maximum Operating Temperature	+85 °C

	Välj alla
	Brand Renesas Electronics
	Family Name R8C
	Package Type LQFP
	Mounting Type Surface Mount
	Pin Count 52
	Device Core R8C / Tiny Series CPU
	Data Bus Width 16bit
	Program Memory Size 16 (ROM) kB, 2 (Flash) kB
	Maximum Frequency 20MHz
	RAM Size 1 kB
	USB Channels 0
	Number of PWM Units 0
	Typical Operating Supply Voltage 2.2 → 5.5 V
	Height 1.55mm
	Width 10.1mm
	Dimensions 10.1 x 10.1 x 1.55mm
	Number of ADC Units 1
	Length 10.1mm
	ADCs 1 (12 x 10 bit)
	Maximum Number of Ethernet Channels 0
	Instruction Set Architecture CISC
	Minimum Operating Temperature -20 °C
	Program Memory Type Flash, ROM
	Maximum Operating Temperature +85 °C

COO (Country of Origin):: CN

RX63N Microcontrollers

The RX63N family of 32-bit microcontrollers features 100MHz high-speed operation, large-capacity on-chip memory and Ethernet communication.

• 100MHz 32-bit RX core microcontroller
• Up to 2MB Flash memory
• 32KB Data Flash memory
• 32-bit multiplier/divider with multiply-accumulate
• Single-precision IEEE 754 Floating Point maths unit
• AES-128/192/256 Data Encryption unit (Selected devices)
• 4-channel DMA controller
• Data Transfer Controller
• Serial Communication: SPI, I²C, USB, CAN, Ethernet
• 14-bit Independent Watchdog Timer
• Programmable Pulse Generator
• Real-Time Clock
• CRC Calculator
• Temperature sensor
• On-chip debug and trace
• Power supply: +2.7 to +3.6Vdc
• Low-Power Modes: Sleep, All-module clock stop, Software standby, Deep software standby

Enheter	Per enhet	Per Påse*
2 - 8	44,98 kr	89,96 kr
10 - 18	42,86 kr	85,72 kr
20 - 38	41,465 kr	82,93 kr
40 - 98	39,55 kr	79,10 kr
100 +	38,465 kr	76,93 kr

Renesas Electronics, 16bit R8C / Tiny Series CPU, R8C Microcontroller, 20MHz, 16 (ROM) kB, 2 (Flash) kB Flash, ROM,
