Osram 18 W Electronic Compact Fluorescent Lighting Ballast, 240 V
- RS-artikelnummer:
- 873-5108
- Tillv. art.nr:
- 4008321537065
- Tillverkare / varumärke:
- Osram
För närvarande inte tillgänglig
Vi vet inte om den här artikeln kommer tillbaka i lager, RS har för avsikt att ta bort den från vårt utbud snart.
- RS-artikelnummer:
- 873-5108
- Tillv. art.nr:
- 4008321537065
- Tillverkare / varumärke:
- Osram
Specifikationer
Datablad
Lagstiftning och ursprungsland
Produktdetaljer
Hitta liknande produkter genom att välja ett eller flera attribut.
Välj alla | Attribut | Värde |
|---|---|---|
| Brand | Osram | |
| Product Type | Lighting Ballast | |
| Number of Lamps | 2 | |
| Ballast Type | Electronic | |
| Compatible Lamp Type | Compact Fluorescent | |
| Voltage | 240 V | |
| Dimmable | No | |
| High Frequency | Yes | |
| Length | 103mm | |
| Compatible Lamp Designation | CFL | |
| Lighting Power | 18 W | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | 50°C | |
| Standards/Approvals | EU, REACH, RoHS | |
| Height | 31mm | |
| Width | 67 mm | |
| Series | QUICKTRONIC | |
| Välj alla | ||
|---|---|---|
Brand Osram | ||
Product Type Lighting Ballast | ||
Number of Lamps 2 | ||
Ballast Type Electronic | ||
Compatible Lamp Type Compact Fluorescent | ||
Voltage 240 V | ||
Dimmable No | ||
High Frequency Yes | ||
Length 103mm | ||
Compatible Lamp Designation CFL | ||
Lighting Power 18 W | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature 50°C | ||
Standards/Approvals EU, REACH, RoHS | ||
Height 31mm | ||
Width 67 mm | ||
Series QUICKTRONIC | ||
QUICKTRONIC PROFESSIONAL M Electronic Control Gear for Compact Fluorescent Lamps
The Osram Quicktronic Professional M is an electronic control gear for compact fluorescent lamps. This ECG guarantees a long lamp life and is not affected by frequent on/off switching. The Quicktronic Professional M is the perfect electronic ballast for use with motion sensor lighting.
Ideal applications for the Quicktronic-M ECG are in emergency lighting systems, public buildings, sports halls, factories, also suitable for luminaires of protection class I.
Long lamp life
No adverse effect from frequent on/off switching
Perfect lamp start for applications with motion sensors
Supply voltage: 220-240V
Line voltage: 198-264V
Line frequency: 0 Hz | 50 Hz | 60 Hz
Lamp start with optimum filament preheating
Energy Efficiency Index EEI: A2
Automatic shutdown of defective lamps and at end of life
