ABB 4P Pole Isolator Switch - 16A Maximum Current

Se alla Isolator Switches

Antal (1 enhet)*

544,67 kr

(exkl. moms)

680,84 kr

(inkl. moms)

Add to Basket
välj eller skriv kvantitet
Tillfälligt slut
  • Leverans från den 27 februari 2026
Behöver du mer? Ange den kvantitet du behöver och klicka på "Kontrollera leveransdatum"
Enheter
Per enhet
1 +544,67 kr

*vägledande pris

RS-artikelnummer:
175-5095
Tillv. art.nr:
2CDD284101R0016 SD204/16
Tillverkare / varumärke:
ABB
Hitta liknande produkter genom att välja ett eller flera attribut.
Välj alla

Brand

ABB

Number of Poles

4P

Maximum Current

16A

Voltage Rating

440V ac

Accepts Padlocks

Yes

Normal State Configuration

4NO

Series

SD204

Auxiliary Contacts Available

Yes

Range

Pro M Compact

Length

70mm

Width

69mm

Depth

88mm

Terminal Type

Screw

Throw Configuration

4PST

Maximum Operating Temperature

+55°C

Minimum Operating Temperature

-25°C

The SD 200 extends the proven System pro M compact ® series by a new range of switch disconnectors which provides state-of-the-art safety and comfort. The series is available with 1 to 4 poles with rated currents from 16 to 63 A and provides disconnection properties. With a rated voltage of 253/440 V AC, a rated conditional short-circuit current of 25 kA, terminals with protection from misconnection, a “Real CPI” contact position indication, as well as full compatibility with all MCB accessories, SD 200 is unique in its field of application.

Clear contact position indication in red/green (“Real CPI”)
Highest performance at an increased voltage level
35 mm² cylinder lift terminal with 2 terminal openings
Consistent design to other System pro M DIN rail products
Cross wiring with MCBs or RCDs using busbars PS
Durable device identification due to laser labeling
Captive screws with recessed head
