RS PRO Silikonvärmematta, 2.5 W Rektangel, 200 °C, 24V dc

Se alla Värmeplattor
Mängdrabatt möjlig

Antal (1 enhet)*

331,52 kr

(exkl. moms)

414,40 kr

(inkl. moms)

Add to Basket
välj eller skriv kvantitet
Lagerinformation är för närvarande otillgänglig - kom tillbaka senare

Enheter
Per enhet
1 - 4331,52 kr
5 - 9317,86 kr
10 +311,14 kr

*vägledande pris

RS-artikelnummer:
245-506
Tillverkare / varumärke:
RS PRO
Hitta liknande produkter genom att välja ett eller flera attribut.
Välj alla

Varumärke

RS PRO

Mattform

Rektangel

Produkttyp

Silikonvärmematta

Effektklassning

2.5W

Diameter

75mm

Högsta temperatur

200°C

Maximal matningsspänning

24V dc

Standarder/godkännanden

No

RS PRO Adhesive Silicone Heater Mat, 50 mm x 50 mm, 12 V dc


Precise and flexible heat distribution plays a crucial role in many applications where temperature control system for heating, warm and frost protection in drums, cylinders or hoppers machinery is invaluable in heating technology.

The construction of the heating element has a simple concept by laminating spaced resistance wires between two sheets of silicone rubber to improve heat transfer and speed warm-ups of the industrial applications.

In the jungle of different wire mats available on the market, it could be a time-consuming exercise to find the right silicone heaters for your project. We have a solution to this problem as our dedicated, carefully selected heaters offer high-quality while keeping your budget under control.

Today, we are proudly introducing our own branded RS PRO Adhesive Silicone Mat designed for areas where standard heating methods are challenging to apply. Our Mat is self-adhesive and has etched foil element embedded into a glass cloth supported rubber compound.

It is worth to note that control of the temperature should always be in place, and the safety margin applied as the maximum peak temperature for this silicone part should never exceed +180°C.

Features and Benefits


  • Backing adhesive from Nitto, no loss in performance

  • Thin and lightweight

  • The Mat is less thermal mass

  • Flexible Silicone with etched foil heating elements

  • Fits to irregularly shaped objects

  • The wire offers a wide temperature range

  • 240 V ac type mats have a circular hole in the centre which can accept a bi-metallic

  • The Silicone is available in square, rectangular and round shapes

    • Applications


    The Silicone Rubber with a diverse range of industries across multiple sectors makes them ideal, particularly in:

  • Production of heaters

  • Automotive Industries

  • GRP (Glass Reinforced Plastic) repairs

  • Heating lower / medium temperature drums, cylinders, flat plates, water basins or food process machinery

    • Why RS PRO?


    RS PRO is our own-brand range of great-value products. Each part of every RS PRO product is stringently tested against demanding industry standards. We give it our seal of approval only when we're confident of exceptional quality. That's why RS PRO is trusted by engineers worldwide.

    Processvärmare för flera ändamål


    För att få optimal prestanda från dessa produkter rekommenderas att temperaturavkänning och styrningselement används med dem.

    Note

    To make sure the optimum performance for this heater is achievable, both temperature sensing and control elements should play together.

    Caution

    Heater mats are not suitable for stand-alone operation

    Warning

    Dessa värmare får endast användas där tillräckliga elektriska, termiska och mekaniska barriärer tillhandahålls för att förhindra åtkomst till farliga delar utan användning av verktyg.
