Vishay Bridge Rectifier, 600 V 420 A, 4-Pin Single
- RS-artikelnummer:
- 145-1574
- Tillv. art.nr:
- VS-GBPC2506A
- Tillverkare / varumärke:
- Vishay
Mängdrabatt möjlig
Antal (1 låda med 100 enheter)*
4 831,20 kr
(exkl. moms)
6 039,00 kr
(inkl. moms)
GRATIS leverans för online beställningar över 500,00 kr
I lager
- 500 enhet(er) är redo att levereras
Behöver du mer? Ange den kvantitet du behöver och klicka på "Kontrollera leveransdatum"
Enheter | Per enhet | Per låda* |
|---|---|---|
| 100 - 100 | 48,312 kr | 4 831,20 kr |
| 200 + | 45,898 kr | 4 589,80 kr |
*vägledande pris
- RS-artikelnummer:
- 145-1574
- Tillv. art.nr:
- VS-GBPC2506A
- Tillverkare / varumärke:
- Vishay
Specifikationer
Datablad
Lagstiftning och ursprungsland
Produktdetaljer
Hitta liknande produkter genom att välja ett eller flera attribut.
Välj alla | Attribut | Värde |
|---|---|---|
| Brand | Vishay | |
| Product Type | Bridge Rectifier | |
| Peak Reverse Repetitive Voltage Vrrm | 600V | |
| Mount Type | Screw | |
| Number of Phases | 1 | |
| Package Type | GBPC | |
| Pin Count | 4 | |
| Configuration | Single | |
| Maximum Operating Temperature | 150°C | |
| Peak Non-Repetitive Forward Surge Current Ifsm | 420A | |
| Minimum Operating Temperature | -55°C | |
| Forward Current If | 25A | |
| Peak Forward Voltage Vf | 1.1V | |
| Standards/Approvals | No | |
| Length | 28.6mm | |
| Series | VS-GBPC | |
| Height | 7.7mm | |
| Width | 28.6 mm | |
| Peak Reverse Current Ir | 5μA | |
| Automotive Standard | No | |
| Välj alla | ||
|---|---|---|
Brand Vishay | ||
Product Type Bridge Rectifier | ||
Peak Reverse Repetitive Voltage Vrrm 600V | ||
Mount Type Screw | ||
Number of Phases 1 | ||
Package Type GBPC | ||
Pin Count 4 | ||
Configuration Single | ||
Maximum Operating Temperature 150°C | ||
Peak Non-Repetitive Forward Surge Current Ifsm 420A | ||
Minimum Operating Temperature -55°C | ||
Forward Current If 25A | ||
Peak Forward Voltage Vf 1.1V | ||
Standards/Approvals No | ||
Length 28.6mm | ||
Series VS-GBPC | ||
Height 7.7mm | ||
Width 28.6 mm | ||
Peak Reverse Current Ir 5μA | ||
Automotive Standard No | ||
Bridge Rectifiers with Push-on Terminals, VS-GBPC25 Series, Vishay Semiconductor
Universal, 3-way terminals: Push-on, wrap around or solder
High thermal conductivity package, electrically insulated case
Center hole fixing
Excellent power/volume ratio
Bridge Rectifiers - Vishay Semiconductor
The Bridge Rectifier converts an Alternating Current (AC) input into a Direct Current (DC) output for full-wave rectification applications. The diode arrangement provides the same polarity of output for either polarity of input. A three-phase full-wave rectifier is an arrangement of six diodes in a bridge circuit configuration. The packages are designed for minimal size, highest reliability and maximum thermal performance.
Approvals
UL E54214
