Barrier Strips

Barrier strips are screw-type electrical connectors that allow more than one circuit to connect to another circuit. Wires are clamped down to a metal part by tightening of a screw. Multiple screw terminals are arranged such that the metal strips are separated by a barrier or insulating block.


How do barrier strips work?


Each strip will have a pair of screws arranged such that each screw connects to a separate conductor on either end of the strip. Alternatively, terminal strips have several screws along two strips, creating a bus bar for the distribution of power.


Barrier strips can accommodate a broad range of wire sizes and provide reliable connection. The term “contact” refers to the wire attached to the barrier and the contact pitch refers to the distance between each contact, measured from the centre of each opening or hole.


Applications of Barrier strips


Barrier strips are extensively used in electrical wiring for distributing electricity, connecting switches, electrical outlets and lighting fixtures to the mains. They’re also used to directly connect major appliances such as ovens. You will also find barrier strips in surge protectors and speakers.


...
Read more Read less

Filter

Visar 1 - 20 av 153 produkter
Resultat per sida
Beskrivning Pris Number of Contacts Pitch Body Orientation Contact Material Contact Plating Number of Rows Screw Size Wire Size Material Fixing Centre Current Rating Voltage Rating Dimensions Depth
RS-artikelnummer 123-4541
VarumärkeRS PRO
29,55 kr
Each
Enheter
40 6mm - Steel Tin 4 - - - - - 12 V 86 x 56 x 7.5mm 7.5mm
RS-artikelnummer 822-7225
Tillv. art.nr38770-0112
VarumärkeMolex
52,73 kr
Each
Enheter
12 9.53mm Straight Brass Nickel 2 6 → 32 - PBT - - - 130.9 x 22.4 x 11.2mm 11.2mm
RS-artikelnummer 433-703
VarumärkeRS PRO
34,568 kr
Each (In a Pack of 5)
Enheter
36 6.35mm - - - 2 - - - - - - 117 x 38 x 7.5mm 38mm
RS-artikelnummer 885-9285
Tillv. art.nr18-140
VarumärkeCinch Connectors
107,12 kr
Each
Enheter
18 9.53mm Straight Brass Nickel 2 5 → 40 16 AWG Phenolic 180.98mm 15A 250 V ac 188.14 x 22.23 x 10.31mm 10.31mm
RS-artikelnummer 822-7171
Tillv. art.nr38760-0112
VarumärkeMolex
53,04 kr
Each
Enheter
12 9.53mm Straight Brass Nickel 2 6 → 32 24 → 12 AWG Thermoplastic - - - 130.9 x 22.4 x 16mm 16mm
RS-artikelnummer 822-7105
Tillv. art.nr38721-6703
VarumärkeMolex
29,47 kr
Each
Enheter
3 9.53mm Straight Brass Tin 1 6 → 32 - PBT - - - 49.7 x 15.7 x 16.8mm 16.8mm
RS-artikelnummer 822-7203
Tillv. art.nr38770-0105
VarumärkeMolex
25,85 kr
Each
Enheter
5 9.53mm Straight Brass Nickel 2 6 → 32 - PBT - - - 64.3 x 22.4 x 11.2mm 11.2mm
RS-artikelnummer 822-7174
Tillv. art.nr38760-0109
VarumärkeMolex
39,60 kr
Each
Enheter
9 9.53mm Straight Brass Nickel 2 6 → 32 24 → 12 AWG Thermoplastic - - - 102.4 x 22.4 x 16mm 16mm
RS-artikelnummer 885-9314
Tillv. art.nr12-141
VarumärkeCinch Connectors
93,99 kr
Each
Enheter
12 11.13mm Straight Brass Nickel 2 6 → 32 14 AWG Phenolic 144.45mm 20A 250 V ac 152.4 x 28.58 x 12.7mm 12.7mm
RS-artikelnummer 782-2888
Tillv. art.nr1546310-6
VarumärkeTE Connectivity
78,11 kr
Each
Enheter
6 14.27mm - - - 2 - 22 → 10 AWG - - 30A 300 V - -
RS-artikelnummer 885-9276
Tillv. art.nr10-140
VarumärkeCinch Connectors
66,28 kr
Each
Enheter
10 9.53mm Straight Brass Nickel 2 5 → 40 16 AWG Phenolic 104.78mm 15A 250 V ac 111.94 x 22.23 x 10.31mm 10.31mm
RS-artikelnummer 161-5083
Tillv. art.nr1-1437667-0
VarumärkeTE Connectivity
12,004 kr
Each (In a Bag of 56)
Enheter
4 8.26mm Straight Copper Alloy Tin 1 6 → 32 22 → 12 AWG Nylon - 20A 300 V 34.67 x 13.46 x 12.7mm 12.7mm
RS-artikelnummer 822-7109
Tillv. art.nr38721-6704
VarumärkeMolex
13,986 kr
Each (In a Pack of 260)
Enheter
4 9.53mm Straight Brass Tin 1 6 → 32 - PBT - - - 59.2 x 15.7 x 16.8mm 16.8mm
RS-artikelnummer 822-7253
Tillv. art.nr38780-0110
VarumärkeMolex
53,25 kr
Each
Enheter
10 11.11mm Straight Brass Nickel 2 6 → 32 - Thermoplastic - - - 130.2 x 28.6 x 14mm 14mm
RS-artikelnummer 822-7054
Tillv. art.nr38720-3203
VarumärkeMolex
23,37 kr
Each
Enheter
3 9.53mm Straight Brass Tin 1 6 → 32 - Thermoplastic - - - 49.7 x 15.7 x 16.8mm 16.8mm
RS-artikelnummer 822-7206
Tillv. art.nr38770-0106
VarumärkeMolex
37,43 kr
Each
Enheter
6 9.53mm Straight Brass Nickel 2 6 → 32 - PBT - - - 73.8 x 22.4 x 11.2mm 11.2mm
RS-artikelnummer 804-5749
Tillv. art.nr3240252
VarumärkePhoenix Contact
23,543 kr
Each (In a Pack of 25)
Enheter
- - - - - - - - - - - - - -
RS-artikelnummer 782-2009
Tillv. art.nr1546306-6
VarumärkeTE Connectivity
17,372 kr
Each (In a Pack of 5)
Enheter
6 9.53mm - Brass Tin 2 UNC 6-32 22 → 12 AWG Thermoplastic - 20A 300 V - -
RS-artikelnummer 885-6848
Tillv. art.nr9-141
VarumärkeCinch Connectors
69,48 kr
Each
Enheter
9 11.13mm Straight Brass Nickel 2 6 → 32 14 AWG Phenolic 111.13mm 20A 250 V ac 119.05 x 28.58 x 12.7mm 12.7mm
RS-artikelnummer 885-6722
Tillv. art.nr5-142
VarumärkeCinch Connectors
62,66 kr
Each
Enheter
5 14.3mm Straight Brass Nickel 2 8 → 32 10 AWG Phenolic 85.73mm 30A 250 V ac 96.04 x 33.32 x 15.88mm 15.88mm
