Solar connectors are used to connect solar panels to other panels, batteries and junction boxes. The most common type of solar connector is the MC4 connector, a standardised single pole connector that has built in strain relief and interlocks. These interlocks ensure a secure mating and protection against accidental release between plugs and sockets. As they are often used outside MC4 connectors are weather-proof, and are paired with cable that is double-insulated and UV resistant.
Branch Connectors are available to assist the connection of solar panels in parallel or series, for example linking multiple panels to a single battery for increased power.
The RS Range of solar connectors includes plugs, sockets and adapters suitable for applications from 15A to 69A applications.
Solar Connectors
Filter
| Beskrivning | Pris | Type | Gender | Cable CSA | Mounting Type | Termination Method | Keying | IP Rating | Current Rating | Voltage Rating | Plug/Socket | Thread Size | Maximum Operating Temperature | Minimum Operating Temperature | Series | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
|
Nytt
|
RS-artikelnummer
190-2002
Tillv. art.nr2270024-1
VarumärkeTE Connectivity
|
10 283,13 kr
1 Bag of 1000
Påse(ar)
|
Connector | Male | 4mm² | Cable Mount | Crimp | Minus | IP68 | 20 (UL) A, 40 (TUV) A | TUV) V dc, 1000 (UL | Plug | - | +85°C | -40°C | SOLARLOK PV4-S |
|
RS-artikelnummer
698-7243
Tillv. art.nr1394462-4
VarumärkeTE Connectivity
|
40,629 kr
Each (In a Pack of 10)
Enheter
|
Coupler | Female | 4mm² | Cable Mount | - | Minus | IP67 | 25A | 1 kV dc | - | - | +150°C | -40°C | - |
|
Nytt
|
RS-artikelnummer
190-2045
Tillv. art.nr1-2306314-1
VarumärkeTE Connectivity
|
66,54 kr
Each
Enheter
|
Junction Box | - | - | - | - | Plus | - | - | - | - | - | - | - | SOLARLOK PV |
|
RS-artikelnummer
175-0097
Tillv. art.nr32.0093P0001-UR
VarumärkeMulti Contact
|
18,48 kr
Each (In a Pack of 5)
Enheter
|
Coupler | Male | - | Cable Mount | Crimp | - | - | 69A | 1.5 kV dc | Plug | - | +85°C | -40°C | MC4-Evo2 |
|
Nytt
|
RS-artikelnummer
193-1796
Tillv. art.nrH4CMC4DI
VarumärkeAmphenol
|
14 891,05 kr
1 Box of 1000
Låda(or)
|
Solar Connector | Male | 4 mm², 12 AWG | Cable Mount | Quick Connect | - | IP68 | 20 (UL) A, 42 (TUV) A | TUV) V, 1500 (UL | Plug | - | +85°C | -40°C | H4 |
|
Nytt
|
RS-artikelnummer
193-1802
Tillv. art.nrH4CFC4DIS
VarumärkeAmphenol
|
23,926 kr
Each (In a Bag of 5)
Enheter
|
Solar Connector | Female | 4 mm², 12 AWG | Cable Mount | Quick Connect | - | IP68 | 20 (UL) A, 42 (TUV) A | TUV) V, 1500 (UL | Socket | - | +85°C | -40°C | H4 |
|
Nytt
|
RS-artikelnummer
193-1805
Tillv. art.nrUTXCFA4AM
VarumärkeAmphenol
|
16,339 kr
Each (In a Box of 800)
Enheter
|
Solar Connector | Female | 4 mm², 12 AWG | Cable Mount | - | - | IP68 | 20 (UL) A, 40 (JET) A, 42 (TUV) A | JET) V, TUV, 1500 (UL | Socket | - | +90°C | -40°C | UTX |
|
RS-artikelnummer
789-3089
Tillv. art.nr130244-0203
VarumärkeMolex
|
26,17 kr
Each
Enheter
|
Power | Female | 2.5mm² | Cable Mount | Crimp | Minus | IP67 | 15A | - | Socket | - | +80°C | -40°C | - |
|
Nytt
|
RS-artikelnummer
190-2010
Tillv. art.nr1-2306314-1
VarumärkeTE Connectivity
|
46,517 kr
Each (In a Box of 72)
Enheter
|
Junction Box | - | - | - | - | Plus | - | - | - | - | - | - | - | SOLARLOK PV |
|
RS-artikelnummer
188-2902
Tillv. art.nr1017635
VarumärkePhoenix Contact
|
163,59 kr
Each
Enheter
|
Circular Connector | Female | 1.5 → 6 mm², 4 → 6 mm² | Front Mount | Screw | - | IP66, IP68, IP69K | 35A | 690 V ac | Socket | - | - | - | PRC 3-FC-FS6 8-21 HR |
|
Nytt
|
RS-artikelnummer
190-2009
Tillv. art.nr1-2306314-5
VarumärkeTE Connectivity
|
45,568 kr
Each (In a Box of 72)
Enheter
|
Junction Box | - | - | - | - | - | - | - | - | - | - | - | - | SOLARLOK PV |
|
RS-artikelnummer
188-2901
Tillv. art.nr1017632
VarumärkePhoenix Contact
|
203,65 kr
Each
Enheter
|
Circular Connector | Female | 1.5 → 6 mm², 4 → 6 mm² | Cable Mount | Screw | - | IP66, IP68, IP69K | 35A | 690 V ac | Socket | - | - | - | PRC 5-FC-FS6 8-21 HR |
