Infineon AC-DC, SMPS Current Mode 5-Channel 16-Pin, DSO
- RS-artikelnummer:
- 166-0804
- Tillv. art.nr:
- ICE3BR4765JGXUMA1
- Tillverkare / varumärke:
- Infineon
För närvarande inte tillgänglig
Vi vet inte om den här artikeln kommer tillbaka i lager, RS har för avsikt att ta bort den från vårt utbud snart.
- RS-artikelnummer:
- 166-0804
- Tillv. art.nr:
- ICE3BR4765JGXUMA1
- Tillverkare / varumärke:
- Infineon
Specifikationer
Datablad
Lagstiftning och ursprungsland
Produktdetaljer
Hitta liknande produkter genom att välja ett eller flera attribut.
Välj alla | Attribut | Värde |
|---|---|---|
| Brand | Infineon | |
| Sub Type | SMPS Current Mode | |
| Product Type | SMPS Controller | |
| Number of Outputs | 5 | |
| Current Conversion Type | AC-DC | |
| Switching Frequency | 73.5kHz | |
| Mount Type | Surface | |
| Package Type | DSO | |
| Pin Count | 16 | |
| Maximum Duty Cycle | 75% | |
| Series | ICE3BR4765JG | |
| Height | 1.75mm | |
| Width | 6.2 mm | |
| Length | 10mm | |
| Standards/Approvals | No | |
| Automotive Standard | No | |
| Maximum Operating Temperature | 150°C | |
| Maximum Input Voltage | 25V | |
| Minimum Operating Temperature | -40°C | |
| Minimum Input Voltage | -0.3V | |
| Välj alla | ||
|---|---|---|
Brand Infineon | ||
Sub Type SMPS Current Mode | ||
Product Type SMPS Controller | ||
Number of Outputs 5 | ||
Current Conversion Type AC-DC | ||
Switching Frequency 73.5kHz | ||
Mount Type Surface | ||
Package Type DSO | ||
Pin Count 16 | ||
Maximum Duty Cycle 75% | ||
Series ICE3BR4765JG | ||
Height 1.75mm | ||
Width 6.2 mm | ||
Length 10mm | ||
Standards/Approvals No | ||
Automotive Standard No | ||
Maximum Operating Temperature 150°C | ||
Maximum Input Voltage 25V | ||
Minimum Operating Temperature -40°C | ||
Minimum Input Voltage -0.3V | ||
- COO (ursprungsland):
- MY
AC-DC Integrated Power Stage - CoolSET™, Infineon
The Infineon Off-line SMPS Current mode controller comes complete with integrated 650V CoolMOS and start up cell (frequency jitter mode). The PMIC BiCMOS technology has a 26V VCC range that covers the changes in the auxiliary supply when the CV/CC regulation is applied to the secondary side. It also has an Active burst mode that offers low standby power as well as auto restart mode features to protect from VCC over-voltage/under-voltage, output open loop and over-temperature The ICE3B1565J has a fixed frequency current mode flyback PWM controller and can be used in a variety of applications from Smart meters, DVD players, set TOP boxes, game consoles along with LED TV’s.
Low standby power <100mW)
Modulated gate drive
Low EMI noise
