WAGO 2273 COMPACT PUSH WIRE Series Junction Box Connector, 2-Way, 24A, 20 → 16 AWG Wire, Push-In Termination

RS-artikelnummer:: 864-8313
Tillv. art.nr:: 2273-202
Tillverkare / varumärke:: WAGO

WAGO 2273 COMPACT PUSH WIRE Series Junction Box Connector, 2-Way, 24A, 20 → 16 AWG Wire, Push-In Termination

Antal (1 förpackning med 10 enheter)*

28,15 kr

(exkl. moms)

35,19 kr

(inkl. moms)

GRATIS leverans för online beställningar över 500,00 kr

I lager

2 630 enhet(er) är redo att levereras
Plus 1 000 enhet(er) är redo att levereras från en annan plats

Behöver du mer? Ange den kvantitet du behöver och klicka på "Kontrollera leveransdatum"

Enheter	Per enhet	Per förpackning*
10 +	2,815 kr	28,15 kr

*vägledande pris

RS-artikelnummer:: 864-8313
Tillv. art.nr:: 2273-202
Tillverkare / varumärke:: WAGO

Specifikationer

Datablad

Lagstiftning och ursprungsland

Produktdetaljer

Hitta liknande produkter genom att välja ett eller flera attribut.

Välj alla	Attribut	Värde
	Brand	WAGO
	Number of Ways	2
	Current Rating	24A
	Wire Size	20 → 16 AWG
	Termination Method	Push-In
	Mounting Type	Cable Mount
	Fused	No
	Voltage Rating	450 V
	Cable CSA	2.5mm²
	Series	2273 COMPACT PUSH WIRE
	Colour	Clear
	Maximum Operating Temperature	+105°C
	Enclosed	Yes

	Välj alla
	Brand WAGO
	Number of Ways 2
	Current Rating 24A
	Wire Size 20 → 16 AWG
	Termination Method Push-In
	Mounting Type Cable Mount
	Fused No
	Voltage Rating 450 V
	Cable CSA 2.5mm²
	Series 2273 COMPACT PUSH WIRE
	Colour Clear
	Maximum Operating Temperature +105°C
	Enclosed Yes

Datasheet

COO (Country of Origin):: DE

WAGO Lever Connector, 5.8mm Height, 10mm Width - COMPACT PUSH WIRE2273 Series - 2273-202

Clamp down on a cable in your panel using this lever connector from WAGO. It's a 2-way piece that lets you set up a dual-transmission electrical system. This unit accommodates wire sizes from 20 to 16AWG for flexibility in your cable connections. You can fasten your wire to it by pushing in the stripped end of the conductor until it hits the backstop. The transparent housing gives you a clear internal view to tell easily if the wire is properly attached.

Features & Benefits

• Compact external dimensions of 5.8 (H) x 10 (W) x 16.7mm (D) to fit into busy panels
• Push-in termination enables tool-free connection
• Accepts combined conductor sizes for versatility
• Enclosed structure helps shield cables from contaminants

Applications

• Medical devices
• Building automation
• Control panels
• Communications equipment

What's the current capacity of this connector?

Thanks to a current rating of 24A, you can use this connector safely in your heavy-duty machinery.

How do I remove a wire from this connector?

Simply hold the conductor and twist it left and right while pulling the connector to remove the wire.
