Finder 41 Series Solid State Relay, 3 A Load, PCB Mount, 240 V ac Load, 17 V dc Control
- RS-artikelnummer:
- 708-3112
- Tillv. art.nr:
- 41.81.7.012.8240
- Tillverkare / varumärke:
- Finder
Mängdrabatt möjlig
Antal (1 enhet)*
318,75 kr
(exkl. moms)
398,44 kr
(inkl. moms)
GRATIS leverans för online beställningar över 500,00 kr
I lager
- 14 enhet(er) är redo att levereras
- Dessutom levereras 18 enhet(er) från den 31 december 2025
Behöver du mer? Ange den kvantitet du behöver och klicka på "Kontrollera leveransdatum"
Enheter | Per enhet |
|---|---|
| 1 - 9 | 318,75 kr |
| 10 - 24 | 293,33 kr |
| 25 - 49 | 280,45 kr |
| 50 + | 270,82 kr |
*vägledande pris
- RS-artikelnummer:
- 708-3112
- Tillv. art.nr:
- 41.81.7.012.8240
- Tillverkare / varumärke:
- Finder
Specifikationer
Datablad
Lagstiftning och ursprungsland
Produktdetaljer
Hitta liknande produkter genom att välja ett eller flera attribut.
Välj alla | Attribut | Värde |
|---|---|---|
| Brand | Finder | |
| Maximum Load Current | 3 A | |
| Mounting Type | PCB Mount | |
| Maximum Load Voltage | 240 V ac | |
| Minimum Load Voltage | 12 V ac | |
| Minimum Control Voltage | 8 V dc | |
| Maximum Control Voltage | 17 V dc | |
| Switching Type | Zero Cross | |
| Control Voltage Range | 8 → 17 V dc | |
| Minimum Load Current | 50 mA | |
| Number of Poles | 1 | |
| Terminal Type | Through Hole | |
| Contact Configuration | SPST | |
| Relay Type | Solid State Relay | |
| Maximum Turn On Time | 10ms | |
| Load Voltage Range | 12 → 240V ac | |
| Series | 41 | |
| Dimensions | 29 x 12.7 x 15.7mm | |
| Maximum Operating Temperature | +60°C | |
| Depth | 12.7mm | |
| Operating Temperature Range | -20 → +60°C | |
| Height | 15.7mm | |
| Off State Leakage Current | 1 mA | |
| Length | 29mm | |
| Standards Met | cURus, EAC | |
| Minimum Operating Temperature | -20°C | |
| Välj alla | ||
|---|---|---|
Brand Finder | ||
Maximum Load Current 3 A | ||
Mounting Type PCB Mount | ||
Maximum Load Voltage 240 V ac | ||
Minimum Load Voltage 12 V ac | ||
Minimum Control Voltage 8 V dc | ||
Maximum Control Voltage 17 V dc | ||
Switching Type Zero Cross | ||
Control Voltage Range 8 → 17 V dc | ||
Minimum Load Current 50 mA | ||
Number of Poles 1 | ||
Terminal Type Through Hole | ||
Contact Configuration SPST | ||
Relay Type Solid State Relay | ||
Maximum Turn On Time 10ms | ||
Load Voltage Range 12 → 240V ac | ||
Series 41 | ||
Dimensions 29 x 12.7 x 15.7mm | ||
Maximum Operating Temperature +60°C | ||
Depth 12.7mm | ||
Operating Temperature Range -20 → +60°C | ||
Height 15.7mm | ||
Off State Leakage Current 1 mA | ||
Length 29mm | ||
Standards Met cURus, EAC | ||
Minimum Operating Temperature -20°C | ||
Finder Series 41 Solid State Relay, 3A Maximum Load Current, 240V Maximum Load Voltage - 41.81.7.012.8240
This solid state relay, designed for PCB mounting, is engineered to handle loads effectively with a maximum load current of 3A and a load voltage range spanning from 12V to 240V AC. Its compact dimensions of 29 x 12.7 x 15.7mm enable seamless integration into electronic circuits, maintaining efficient operation within an operating temperature range of -20°C to +60°C.
Features & Benefits
• Silent operation with zero crossing technology enhances performance
• Reliable switching at 3A for 240V AC applications provides versatility
• Minimum load current of 50mA ensures effective activation
• Robust insulation rated at 2500V AC protects against electrical faults
• Compact design facilitates space-saving installation on PCB
• Parameter specifications meet stringent standards for electrical safety
• Reliable switching at 3A for 240V AC applications provides versatility
• Minimum load current of 50mA ensures effective activation
• Robust insulation rated at 2500V AC protects against electrical faults
• Compact design facilitates space-saving installation on PCB
• Parameter specifications meet stringent standards for electrical safety
Applications
• Used for controlling industrial robots and building automation systems
• Ideal for electronic circuit boards and lighting controls
• Commonly implemented in vending machines and door openers
• Utilised in control systems requiring precise activation
• Suitable for timers in mechanical and electrical setups
• Ideal for electronic circuit boards and lighting controls
• Commonly implemented in vending machines and door openers
• Utilised in control systems requiring precise activation
• Suitable for timers in mechanical and electrical setups
What is the range of control voltage for this relay?
The control voltage range is from 8V to 17V DC, providing flexibility in various applications.
How does the zero cross feature benefit operation?
Zero crossing technology minimises stress on devices by switching at voltage zero points, reducing electromagnetic interference and extending lifecycle.
What is the maximum off-state leakage current associated with this relay?
The maximum off-state leakage current is 1mA, ensuring minimal power loss when the relay is not in operation.
What protection against voltage surges does it provide?
This relay is designed with a dielectric strength of 2500V AC between input and output, offering robust protection against voltage surges.
