    Allen Bradley Guardmaster 440K Safety Interlock Switch, 2NC/1NO, Keyed Actuator Included, Glass Filled PBT

    RS-artikelnummer:
    251-2016
    Tillv. art.nr:
    440K-T11118
    Tillverkare / varumärke:
    Allen Bradley Guardmaster
    Allen Bradley Guardmaster
    Se alla Safety Interlock Switches
    99 I lager för avsändande samma dag
    Add to Basket
    Enheter

    Lagt till varukorgen

    Pris (ex. moms) Each

    664,90 kr

    (exkl. moms)

    831,12 kr

    (inkl. moms)

    EnheterPer unit
    1 +664,90 kr
    RS-artikelnummer:
    251-2016
    Tillv. art.nr:
    440K-T11118
    Tillverkare / varumärke:
    Allen Bradley Guardmaster

    Ej tillämpbart

    COO (Country of Origin):
    DO

    Lagstiftning och ursprungsland

    Ej tillämpbart

    COO (Country of Origin):
    DO

    Produktdetaljer

    Allen Bradley Guardmaster - Trojan 5 Safety Interlock Switches


    Give your machine guard door a safety upgrade with the Trojan™ 5 Safety Switches by Allen Bradley Guardmaster.


    The Trojan 5 switches are universal tongue (or key) operated interlock switches which prevent access to hazardous areas where machinery may be in motion. They have dual key entry slots and rotatable heads, which can be moved by releasing the cover screws, and offer four actuator entry options. They are designed to fit the leading edge of sliding, hinged or lift-off guards. They are easy to install and are operated by inserting a specially-profiled stainless steel key that is permanently attached to the leading edge of the guard door. The actuator is tamper resistant and will only operate when mounted to the guard, ensuring optimal security and stability.


    These switches have 3 sets of contacts: 1 NO (Normally Open) / 2 NC (Normally Closed). They are sealed to IP67, making them suitable for use in wet environments where machinery is regularly washed down. They are also fully protected against ingress of dust. All switches come with an actuator.


    Cat. 1 device per EN 954-1 dual channel interlocks suitable for Cat. 3 or 4 systems.


    Forced guided contacts - complies with EN 1088, IEC 947-5-1
    CE Marked for all applicable directives, cULus, TÜV, and CCC


    Standards


    EN 954-1, ISO 13849-1, IEC/EN 60204-1, NFPA 79, EN 1088, ISO 14119, IEC/EN 60947-5-1, ANSI B11.19, AS 4024.1.


    440K-T11118 Safety-Rated Switch


    The 440K-T11118 Trojan 5 tongue interlock switch by Allen Bradley Guardmaster has Make Before Break Action and includes a standard type actuator made of durable stainless-steel. It has convenient M20 Conduit entry and a maximum current of 6A. The operating temperature is -20°C to +80°C (-4°F to +176°F). Rated insulation voltage is 500V. The housing material is comprised of tough UL approved glass-filled PBT. The 440K safety switches provide cost-effective, secure electrical interlocking of the guard to the machine’s control circuit.


    Features and Benefits:


    • Easy installation
    • Versatile switch with rotatable head to allow 4 possible actuator entry positions, for greater application flexibility
    • Tamper resistant due to self-ejecting actuator that operates only when mounted to the guard
    • 3 sets of contacts – 2NC Safety, 1NO Auxiliary
    • Forced guided contacts
    • Durable and versatile - can be used in most applications


    Certifications:


    EN 954-1
    ISO 13849-1
    IEC/EN 60204-1
    NFPA 79
    EN 1088
    ISO 14119
    IEC/EN 60947-5-1
    ANSI B11.19
    AS 4024.1
    cULus listed
    TÜV certified
    CCC certified
    IP67 rated (Enclosure)


    Note: This device can be used with GuardLink, a new safety linking technology from Allen Bradley Guardmaster. GuardLink simplifies and reduces the connection time of the safety system, whilst providing real-time diagnostic information over Ethernet IP. This makes it simple to identify the location of the device that has tripped the system, thus reducing downtime, and improving the machines overall efficiency. For more details, please go to the GuardLink brochure.


    What is a Safety Interlock Switch?


    A safety interlock switch is a device which keeps guard doors and gates securely locked to prevent access to areas where dangerous machinery may be in operation, minimalising the risk of injury to personnel and damage to machinery. They can also be used to monitor the status of the machine guard, and to ensure that machinery cannot start up or run while the guard door is open. They are often utilised in industrial applications, such as safeguarding factory production lines. They can vary in lock type, maximum current and voltage, and housing material. Safety-rated interlock switches are specifically designed to meet high machine safety standards. Allen Bradley Guardmaster switches are built to global standards to provide exceptional quality and reliability.



    Interlock Switch


    Specifikationer

    AttributeValue
    Lock StyleKeyed
    Normal State Configuration2NC/1NO
    Lock TypeInterlock
    Actuator IncludedYes
    Safety Contacts2NC
    Maximum AC Voltage240V
    Maximum DC Voltage24V
    Connection TypeM20
    Housing MaterialGlass Filled PBT
    RangeTrojan 5
    IP RatingIP67
    Number of Head Directions4
    Series440K
    Auxiliary Contacts1NO
    Depth52mm
    Length95mm
    Width32mm
    Minimum Operating Temperature-20°C
    Maximum Current6A
    Maximum Operating Temperature+80°C
