Renesas Electronics RAA2124214GNP#MA0, Dual PWM Controller, 40 V, 2 MHz, 500 kHz 22-Pin, TDFN
- RS-artikelnummer:
- 193-1547
- Tillv. art.nr:
- RAA2124214GNP#MA0
- Tillverkare / varumärke:
- Renesas Electronics
För närvarande inte tillgänglig
Vi vet inte om den här artikeln kommer tillbaka i lager, RS har för avsikt att ta bort den från vårt utbud snart.
- RS-artikelnummer:
- 193-1547
- Tillv. art.nr:
- RAA2124214GNP#MA0
- Tillverkare / varumärke:
- Renesas Electronics
Specifikationer
Datablad
Lagstiftning och ursprungsland
Produktdetaljer
Hitta liknande produkter genom att välja ett eller flera attribut.
Välj alla | Attribut | Värde |
|---|---|---|
| Brand | Renesas Electronics | |
| Maximum Switching Frequency | 2 MHz, 500 kHz | |
| Output Voltage | 0.8 to 5.5 V | |
| Output Current | 1.1 A | |
| Number of Outputs | 2 | |
| Mounting Type | Surface Mount | |
| Package Type | TDFN | |
| Pin Count | 22 | |
| Dimensions | 6 x 3 x 0.7mm | |
| Length | 6mm | |
| PWM Controller Type | LDO | |
| Width | 3mm | |
| Height | 0.7mm | |
| Maximum Operating Temperature | +125 °C | |
| Minimum Operating Supply Voltage | 3 V | |
| Minimum Operating Temperature | -40 °C | |
| Maximum Operating Supply Voltage | 40 V | |
| Välj alla | ||
|---|---|---|
Brand Renesas Electronics | ||
Maximum Switching Frequency 2 MHz, 500 kHz | ||
Output Voltage 0.8 to 5.5 V | ||
Output Current 1.1 A | ||
Number of Outputs 2 | ||
Mounting Type Surface Mount | ||
Package Type TDFN | ||
Pin Count 22 | ||
Dimensions 6 x 3 x 0.7mm | ||
Length 6mm | ||
PWM Controller Type LDO | ||
Width 3mm | ||
Height 0.7mm | ||
Maximum Operating Temperature +125 °C | ||
Minimum Operating Supply Voltage 3 V | ||
Minimum Operating Temperature -40 °C | ||
Maximum Operating Supply Voltage 40 V | ||
The RAA212421 is a dual-output regulator combining a 3V to 40V input, 1.1A synchronous buck converter with a 500mA LDO featuring fast transient response. The combination of two high-performance power supplies in one compact 3x6mm package provide an easy-to-use, high-efficiency compact solution.
The wide VIN buck regulator of the RAA212421 integrates both high-side and low-side nMOSFETs and features a PFM mode for improved efficiency at light load. This feature can be disabled if forced PWM mode is desired. It can use internal or external compensation, which minimizes the required external components, reduces BOM count and complexity of design. The part switches at a default frequency of 500kHz, however, it can also be programmed using an external resistor from 300kHz to 2MHz.
