Banner OTB Series Illuminated Push Button Switch, Momentary, 1-3/16 in Cutout, Red LED, IP66

Se alla Push Button Switches
Mängdrabatt möjlig

Antal (1 enhet)*

2 093,62 kr

(exkl. moms)

2 617,02 kr

(inkl. moms)

Add to Basket
välj eller skriv kvantitet
Tillfälligt slut
  • Leverans från den 16 juni 2026
Behöver du mer? Ange den kvantitet du behöver och klicka på "Kontrollera leveransdatum"
Enheter
Per enhet
1 - 42 093,62 kr
5 - 92 027,54 kr
10 +1 944,10 kr

*vägledande pris

RS-artikelnummer:
861-4569
Tillv. art.nr:
OTBVP6QD
Tillverkare / varumärke:
Banner
Hitta liknande produkter genom att välja ett eller flera attribut.
Välj alla

Brand

Banner

Switch Operation

Momentary

Actuator Colour

Black

Product Type

Push Button Switch

Illuminated

Yes

Series

OTB

Panel Cutout Size

1-3/16 in

LED Colour

Red

Terminal Type

Quick Connect

IP Rating

IP66

Minimum Operating Temperature

-20°C

Actuator Style

Rectangular

Maximum Operating Temperature

50°C

Switch Configuration

SPDT

Standards/Approvals

OSHA, ANSI B11LR41887-24E71083

Height

48mm

Length

59.9mm

Width

43.2 mm

COO (Country of Origin):
CN

Opto Touch Switch


The Turck Banner OTB series of touch-activated photoelectric switches are designed to replace capacitive touch switches and mechanical push buttons.

The OTB series of touch button switches are highly resistant to EMI, RFI and ambient light interference.

Contact configuration SPDT 1 x N/O, 1 x N/C

LED indication of ’power on’ and ’output activated’

Black polysulfone (VALOX)housing, epoxy-encapsulated electronics, IP67

Switching current : 7A max. (resistive load)

Operating temperature range: -20 to +50 °C

'Mechanical life: Fifty million operations.

Ambient light immunity 120000 lux

Reduces the risk of repetitive strain injuries

Mounting M30 thread, nuts/washer included

Dimension (mm): 60 x 44 x 36 LWH (excluding threaded portion)

Zero Force & Opto Touch Switches


Actuated by sensors using patented Field Effect Technology which converts the touch of the operators hand into an electrical output. The two sensors have to be touched within 0.2 seconds of each other and can differentiate between a person's hand and most solid objects/substances, as well as resistance to accidental actuation via clothing, fluid, splashes etc.,There are built in diagnostic safeguards for power-up protection, foreign object intervention and film/deposit interference which all result in LED indication.
