Bartec ComEx Series Push Button Module, Panel, 30.3 mm Cutout, DPST, IP20

Se alla Push Button Switches
Mängdrabatt möjlig

Antal (1 enhet)*

956,68 kr

(exkl. moms)

1 195,85 kr

(inkl. moms)

Add to Basket
välj eller skriv kvantitet
I lager
  • Dessutom levereras 22 enhet(er) från den 19 januari 2026
  • Dessutom levereras 4 enhet(er) från den 19 januari 2026
  • Dessutom levereras 12 enhet(er) från den 26 februari 2026
Behöver du mer? Ange den kvantitet du behöver och klicka på "Kontrollera leveransdatum"
Enheter
Per enhet
1 - 4956,68 kr
5 - 11927,02 kr
12 +897,34 kr

*vägledande pris

RS-artikelnummer:
771-9912
Tillv. art.nr:
07-3323-4200+05-0042-0050
Tillverkare / varumärke:
Bartec
Hitta liknande produkter genom att välja ett eller flera attribut.
Välj alla

Brand

Bartec

Product Type

Push Button Module

Actuator Colour

Black

Illuminated

No

Series

ComEx

Panel Cutout Size

30.3 mm

Mount Type

Panel

Contact Configuration

DPST

Terminal Type

Screw

IP Rating

IP20

Minimum Operating Temperature

-55°C

Actuator Style

Round

Maximum Operating Temperature

60°C

Switch Configuration

1 NC, 1 NO, 2 NC, 2 NO

Length

68mm

Height

72mm

Width

38 mm

Standards/Approvals

IEC 60079-0:2007EN 60079-0:2009IEC/EN 60079-1:2007IEC 60079-7:2006EN 60079-7:2007DIN EN 60068-2-27:200930 G18 ms

Switch Contact Current

16 A

COO (Country of Origin):
DE

Switch and Lamp Modules


Switch modules from Bartec can be used in almost all hazardous areas where machine functions are activated by means of a button or a switch. The ComExflex is flexible and in addition to a large number of actuating elements it, it has a junction box. The junction boxes facilitate the use of ComExflex in a control console or a control panel. The junction box features a cable gland and can be combined with various function modules.

All contacts in the switch modules are self-cleaning and the opening contacts have positive opening operation. The ComExflex lamp module indicates command modes by means of a light signal lighting up or going out. It is suitable for use in almost all hazardous areas which a visual indication of a machines functional status is required. The lamp module can be combined with various lamp module actuating elements.

Lamp module comes combined with a push button actuating element and junction box

One module for all fields of application

Illumination 180°

High flexibility due to junction box

Low installation depth

Mounting locked, bayonet lock

Hazardous Area Actuators & Contact Blocks


Panel mounting, with a wide range of switch contact arrangements and elements including; selector switches, key switches, standard pushbuttons and an emergency stop pushbutton. The actuators and lens units require a 30.5mm mounting hole. Ingress protection is to IP66 and they are component-approved in their own right. Switch and lamp modules include three metres of encapsulated cable. Switch modules include a wipe clean action and are rated up to 230Vac/16A (circuit type AC-12). The N/C contact has a positive break action.,The electronic circuitry of each lamp module self configures to allow the lamps to be used over a wide range of ac and dc voltages.,A simple cam arrangement on the modules provides a rapid method for the fitting of the actuators.
