    ABB Compact Series Push Button, Momentary, Panel Mount, 22mm Cutout, SPST, 300V, IP69K

    ABB
    RS-artikelnummer:
    479-3576
    Tillv. art.nr:
    1SFA619100R1012 CP1-10G-10
    Tillverkare / varumärke:
    ABB
    Se alla Push Button Switches
    34 I lager för avsändande samma dag
    Add to Basket
    Enheter

    Lagt till varukorgen

    Pris (ex. moms) Each

    123,08 kr

    (exkl. moms)

    153,85 kr

    (inkl. moms)

    EnheterPer unit
    1 - 4123,08 kr
    5 - 11119,40 kr
    12 +115,51 kr
    RS-artikelnummer:
    479-3576
    Tillv. art.nr:
    1SFA619100R1012 CP1-10G-10
    Tillverkare / varumärke:
    ABB

    Lagstiftning och ursprungsland

    RoHS-status: Inte relevant

    COO (Country of Origin):
    CN

    Produktdetaljer

    Non Illuminated Flush Pushbutton - Momentary


    The ABB CP series of push buttons offer a compact size with built in contact block.

    IP66 rated for harsh environments
    Temperature range - 25 to + 70°C
    22.5mm hole mounting
    Contacts included

    ABB Push Button, 22mm Cutout Diameter, Screw Terminals - Compact Series - 1SFA619100R1012


    For easy manual control over machine functions in your industrial workspace, choose this push button from ABB. As it's a momentary switch, it's only activated when you press it, so it's ideal for short-term operations. The unit fits into a standard cutout diameter of 22mm, so it takes up minimal space on your panel. Thanks to a mechanical durability rating of 500,000 cycles, you can rely on it for long-term performance.

    • Built-in contact block for hassle-free installation
    • Flush mounting style means it won't protrude from your panel to minimise the risk of accidental activation
    • Wide operating temperature range between -25°C and +70°C for use in challenging conditions
    • IP69K rating means it's dust-tight and can withstand high-temperature, high-pressure water jets
    • Light weight of 18g means puts minimal strain on your setup

    Applications


    • Food and beverage processing
    • Test and measurement technology
    • Packaging machines

    What size is this push button?


    This push button has compact dimensions of 30 (H) x 30 (W) x 55mm (D), so it allows you to maximise space on a crowded panel.


    ABB 22.5mm Compact Range


    A comprehensive range of components for the user who wants a reliable and cost-effective solution to meet their needs.

    Specifikationer

    Attribute
    Value
    Switch OperationMomentary
    IlluminatedNo
    Mounting TypePanel Mount
    Push Button StyleRound
    Contact ConfigurationSPST
    Push Button ColourGreen
    Panel Cut Out Diameter22mm
    SeriesCompact
    Push Button MaterialPC
    IP RatingIP69K
    Voltage Rating300V
    Case ColourBlack
    Terminal TypeScrew
    Minimum Operating Temperature-25°C
    Manufacturer Part No.1SFA619100R1012 CP1-10G-10
    Maximum AC Voltage240V
    Maximum DC Voltage250V
    Maximum Operating Temperature+70°C
