TE Connectivity Absolute Pressure Sensor, 5psi Operating Max, Surface Mount, 15psi Overload Max
- RS-artikelnummer:
- 893-7339
- Tillv. art.nr:
- 82-005G-RT
- Tillverkare / varumärke:
- TE Connectivity
Det är tyvärr inte möjligt att visa lagerbehållning för närvarande. Uppdatera sidan och försök igen.
Nästa dag-leverans inte möjlig
Lagt till varukorgen
Pris (ex. moms) Varje
507,90 kr
(exkl. moms)
634,88 kr
(inkl. moms)
| Enheter | Per unit |
| 1 - 4 | 507,90 kr |
| 5 - 9 | 482,46 kr |
| 10 - 24 | 444,41 kr |
| 25 + | 393,64 kr |
- RS-artikelnummer:
- 893-7339
- Tillv. art.nr:
- 82-005G-RT
- Tillverkare / varumärke:
- TE Connectivity
Lagstiftning och ursprungsland
Produktdetaljer
TE Connectivity 82 Compensated Series Pressure Sensors
This TE Connectivity 82 Compensated series of pressure sensors are piezoresistive, media compatible, small profile and packaged in a 316L stainless steel housing. Suitable for OEM applications where compatibility with corrosive media is required, this series is designed for O-Ring mounting or threaded process fittings. This Series also includes an extra laser trimmed resistor that enables span interchangeability to within ±1%, by allowing adjustment of an external differential amplifier. Suitable applications include process control, medical instruments, fresh and waste water measurements, pressure transmitters, partial vacuum gas measurement and tank level systems (RV and industrial).
Features and Benefits
• Solid state reliability
• O-ring mounting or threaded process fittings
• ±0.2% Pressure non linearity
• 1% interchangeable span (provided by gain set resistor)
• O-ring mounting or threaded process fittings
• ±0.2% Pressure non linearity
• 1% interchangeable span (provided by gain set resistor)
Specifikationer
Attribute | Value |
|---|---|
| Maximum Overload Pressure | 15psi |
| Mounting Type | Surface Mount |
| Dimensions | 19 (Dia.) x 7.3mm |
| Maximum Operating Pressure | 5psi |
| Maximum Operating Temperature | +70 °C |
| Maximum Output Voltage | 0.1 V |
| Minimum Output Voltage | 0 V |
| Minimum Operating Temperature | -20 °C |
