RS PRO 3A 250 V ac 400Hz, Chassis Mount RFI Filter, Tab

RS-artikelnummer:: 239-882
Tillverkare / varumärke:: RS PRO

RS PRO 3A 250 V ac 400Hz, Chassis Mount RFI Filter, Tab

Tillfälligt slut i lager – restorder för leverans när den finns i lager

Pris (ex. moms) Varje

530,10 kr

(exkl. moms)

662,62 kr

(inkl. moms)

Enheter	Per unit
1 - 4	530,10 kr
5 - 9	492,95 kr
10 - 24	461,23 kr
25 +	434,73 kr

RS-artikelnummer:: 239-882
Tillverkare / varumärke:: RS PRO

Datablad

Lagstiftning och ursprungsland

COO (Country of Origin):: FI

Produktdetaljer

GFHF Series

General purpose two stage RFI filters incorporating an earth line choke. These filters are specifically designed to provide high level attenuation to unwanted interference that can occur on all three mains lines.
Ideally suited for sensitive electronic equipment that may be used in harsh electrical environments where interference is very intensive. A capacitor discharge resistor is included within the design.
Electrical connections by 250 (1/4 in.) size terminals suitable for soldering or push-on receptacles. Refer to the Connectors - Terminals section.

Approvals

CSA Certified, VDE, SEMKO, MKO, UL recognised.

Approvals

CSA; VDE; SEMKO; FI

Specifikationer

Attribute	Value
Maximum Current Rating	3A
Maximum Voltage Rating	250 V ac
Mounting Type	Chassis Mount
Termination Style	Tab
Series	GFHF
Number of Stages	Two Stage
Operating Frequency	400Hz
Length	46mm
Depth	76mm
Capacitance	100 nF, 2200 x 2pF
Height	28mm
Inductance	2 x 2 mH
Dimensions	46 x 76 x 28mm
Leakage Current	0.2 mA
Minimum Operating Temperature	-25°C
Maximum Operating Temperature	+85°C
