Bourns SMD Non Resettable Fuse 15A, 125V ac
- RS-artikelnummer:
- 191-4587
- Tillv. art.nr:
- SF-2410F1500T-2
- Tillverkare / varumärke:
- Bourns
Denna produkt har utgått
- RS-artikelnummer:
- 191-4587
- Tillv. art.nr:
- SF-2410F1500T-2
- Tillverkare / varumärke:
- Bourns
Hitta liknande produkter genom att välja ett eller flera attribut.
Välj alla | Attribut | Värde |
|---|---|---|
| Brand | Bourns | |
| Current Rating | 15A | |
| Voltage Rating | 125V ac | |
| Fuse Speed | F | |
| Body Material | Ceramic | |
| Body Length | 6.1mm | |
| Body Width | 2.6mm | |
| Body Height | 2.6mm | |
| Breaking Capacity at Maximum Voltage Rating | 200 A @ 86 VAC, 200 A @ 86 VDC, 300 A @ 24 VDC, 50 A @ 65 VAC, 50 A @ 65 VDC | |
| Minimum Operating Temperature | -55°C | |
| Series | SF-2410F-T | |
| Maximum Operating Temperature | +125°C | |
| Resistance | 3mΩ | |
| Dimensions | 6.1 x 2.6 x 2.6mm | |
Välj alla | ||
|---|---|---|
Brand Bourns | ||
Current Rating 15A | ||
Voltage Rating 125V ac | ||
Fuse Speed F | ||
Body Material Ceramic | ||
Body Length 6.1mm | ||
Body Width 2.6mm | ||
Body Height 2.6mm | ||
Breaking Capacity at Maximum Voltage Rating 200 A @ 86 VAC, 200 A @ 86 VDC, 300 A @ 24 VDC, 50 A @ 65 VAC, 50 A @ 65 VDC | ||
Minimum Operating Temperature -55°C | ||
Series SF-2410F-T | ||
Maximum Operating Temperature +125°C | ||
Resistance 3mΩ | ||
Dimensions 6.1 x 2.6 x 2.6mm | ||
