Megger MET1000 Multifunction Tester, RS Calibration
- RS-artikelnummer:
- 225-7887
- Tillv. art.nr:
- 1013-099
- Tillverkare / varumärke:
- Megger
Antal (1 enhet)*
3 481,00 kr
(exkl. moms)
4 351,25 kr
(inkl. moms)
GRATIS leverans för online beställningar över 500,00 kr
I lager
- 4 enhet(er) är redo att levereras
Behöver du mer? Ange den kvantitet du behöver och klicka på "Kontrollera leveransdatum"
Enheter | Per enhet |
|---|---|
| 1 + | 3 481,00 kr |
*vägledande pris
- RS-artikelnummer:
- 225-7887
- Tillv. art.nr:
- 1013-099
- Tillverkare / varumärke:
- Megger
Specifikationer
Datablad
Lagstiftning och ursprungsland
Produktdetaljer
Hitta liknande produkter genom att välja ett eller flera attribut.
Välj alla | Attribut | Värde |
|---|---|---|
| Brand | Megger | |
| Loop Impedance Test Type | Phase to Earth | |
| Calibrated | RSCAL | |
| Model Number p | MET1000 | |
| Maximum Voltage Measurement | 1000V | |
| Continuity Test Current | 3.5mA | |
| IP Rating | IP65 | |
| Maximum Operating Temperature | +55°C | |
| Display Type | LCD, LED | |
| Safety Category | CAT IV | |
| Dimensions | 220 x 57 x 35mm | |
| Battery Type | LR03 1.5V | |
| Safety Category Voltage | 8000V | |
| Maximum Continuity Resistance | 50000Ω | |
| Weight | 200g | |
| Length | 220mm | |
| Operating Temperature Range | -15 → 55 °C | |
| Height | 35mm | |
| Minimum Operating Temperature | -15°C | |
| Power Source | Battery | |
| Width | 57mm | |
| Välj alla | ||
|---|---|---|
Brand Megger | ||
Loop Impedance Test Type Phase to Earth | ||
Calibrated RSCAL | ||
Model Number p MET1000 | ||
Maximum Voltage Measurement 1000V | ||
Continuity Test Current 3.5mA | ||
IP Rating IP65 | ||
Maximum Operating Temperature +55°C | ||
Display Type LCD, LED | ||
Safety Category CAT IV | ||
Dimensions 220 x 57 x 35mm | ||
Battery Type LR03 1.5V | ||
Safety Category Voltage 8000V | ||
Maximum Continuity Resistance 50000Ω | ||
Weight 200g | ||
Length 220mm | ||
Operating Temperature Range -15 → 55 °C | ||
Height 35mm | ||
Minimum Operating Temperature -15°C | ||
Power Source Battery | ||
Width 57mm | ||
- COO (Country of Origin):
- TW
Megger Multifunction Tester, 9999-Count Display, 1000V AC/DC Maximum Voltage Measurement - 1013-099
Fly through your everyday electrical tests with this multifunction tester from Megger. It packs voltage, resistance and continuity testing into one product, so you can cover lots of tasks without the hassle of swapping gear. With a response time of under 0.5s, the tool keeps up with sudden changes to provide accurate data. Handy liquid crystal and LED displays show readings clearly, even in difficult lighting conditions. As the tester comes with a built-in current clamp, it takes close current readings without disrupting your circuit's electrical flow.
Features & Benefits
• Pluggable probe ports for testing in hard-to-reach areas
• IP65 rating indicates resistance to dust and low-pressure water jets, for use in tough settings
• AC voltage accuracy of ±1.5% +5 counts for precise results
• Auto-ranging voltage and continuity testing to skip through set-up
• Ergonomic hand guard for comfortable use over a long shift
• 16 mm width jaw size
• AC/DC Voltage to 1000V
• 200 A AC measurement
• Self Test
• LED and LCD Display
• True RMS on ACV/ACA
• Measures Voltage without batteries
• Single pole voltage test
• Phase rotation indication
• Data Hold
• Detachable Test Probes
• Complies with IEC/EN 61243-3:2014
• CAT IV 600V
• IP65 rating indicates resistance to dust and low-pressure water jets, for use in tough settings
• AC voltage accuracy of ±1.5% +5 counts for precise results
• Auto-ranging voltage and continuity testing to skip through set-up
• Ergonomic hand guard for comfortable use over a long shift
• 16 mm width jaw size
• AC/DC Voltage to 1000V
• 200 A AC measurement
• Self Test
• LED and LCD Display
• True RMS on ACV/ACA
• Measures Voltage without batteries
• Single pole voltage test
• Phase rotation indication
• Data Hold
• Detachable Test Probes
• Complies with IEC/EN 61243-3:2014
• CAT IV 600V
Applications
• Building management
• Processing plants
• Rail industry
• Processing plants
• Rail industry
Can I power this tester from my circuit's electrical supply?
Yes, this device can measure AC voltages from 45V and DC loads down to 35V from a system's power source, providing handy test capabilities without the need for batteries.
