Siretta OSCAR40/5M/LL/SMAM/S/S/33 Whip Multiband Antenna with SMA Male Connector, 5G, 4G, 3G (UMTS), 2G (GSM/GPRS),

RS-artikelnummer:: 124-8868
Tillv. art.nr:: OSCAR40/5M/LL/SMAM/S/S/33
Tillverkare / varumärke:: Siretta

Siretta OSCAR40/5M/LL/SMAM/S/S/33 Whip Multiband Antenna with SMA Male Connector, 5G, 4G, 3G (UMTS), 2G (GSM/GPRS),

Mängdrabatt möjlig

Antal (1 enhet)**

610,96 kr

(exkl. moms)

763,70 kr

(inkl. moms)

395 I lager för avsändande samma dag*

79 Inom 1 arbetsdag(ar) (UK lager)

* Leveransdatumen kan ändras beroende på vald kvantitet och leveransadress.

FRI frakt på alla onlineordrar över 500,00 kr

Finns det i lager?

Enheter	Per enhet
1 - 9	610,96 kr
10 - 24	588,90 kr
25 - 49	564,59 kr
50 - 99	540,74 kr
100 +	519,34 kr

**vägledande pris

RS-artikelnummer:: 124-8868
Tillv. art.nr:: OSCAR40/5M/LL/SMAM/S/S/33
Tillverkare / varumärke:: Siretta

OSCAR40 Antenna Datasheet

The Oscar 40 is an effective wideband antenna solution designed to cover all cellular and non-cellular ISM bands in the 600-6000 MHz frequency range.

With a low VSWR across its operating bandwidth, a radiation efficiency exceeding industry standards, and a consistant omnidirectional radiation pattern, the Oscar 40 is designed to support robust signal reception and transmission for your communication system.

The Oscar 40's radome is UV and water resistant making it a great outdoor antenna. Suitable for discreet omni antenna applications, where a longer one is undesirable, the antenna out-performs many of the larger variants.

The Oscar 40 is fitted with an aluminium bracket for wall mounting and is supplied with a clamp for fitting to a standard mast (see the installation guide for mounting instructions).

Supplied with an FME female connector and 5 meters of LMR195 cable, alternative connectors or cable lengths can be specified for high volume orders.

OSCAR40/10M/LL/SMAM/S/S/33 - 10 m LMR195 cable with SMA male connector (RS 124-8869)
OSCAR40/5M/LL/FMEF/S/S/33 - 5 m LMR195 cable with FME female connector (RS 124-8870)
OSCAR40/5M/LL/SMAM/S/S/33 - 5 m LMR195 cable with SME male connector (RS 124-8868)

Siretta Oscar 40 - 5G/4G, Dual Band Wi-Fi and ISM Omnidirectional Wall/Pole Mount Antenna SMA Male Connector 5M Cable

Key Features

Supports 5G NR / 4G LTE / 3G UMTS / 2G Quad-band GSM
Supports Dual band Wi-Fi 2.4 GHz and 5 GHz
Supports Bluetooth / Zigbee / IEEE 802.15.4 / ISM 2.4 GHz / ISM 5.8 GHz
Supports LoRa / Sigfox / ISM 868 MHz / ISM 915 MHz
Compact size
Wall or pole mount

Additional Considerations

RFID, ISM, Wi-Fi bridging
Public wireless systems
Covers cellular/PCS (US and worldwide)

Electrical Specifications

Impedance: 50 Ohm
Polarization: Vertical
Max Input Power: 50 W
Ground plane independent: Yes

Environmental Specifications

Operating Temperature range: -40 to 70 °C
Storage Temperature range: -50 to 75 °C

Mechanical Specifications

Dimensions: 185 x 60 mm Diameter
Weight: 400 g
Connector: SMA Male
Mounting method: Low Loss Cable
Housing materials: Aluminium (radiator), PVC with UV protection (radome)

Multi-band Antennas, Siretta

Attribute	Value
RF Protocols	5G, 4G, 3G (UMTS), 2G (GSM/GPRS), Wi-Fi, Wi-Fi (Dual Band), Omni-directional, NB-IoT, NB IoT, LoRaWAN, ISM, ISM Band, Cat M, Bluetooth (BLE), IEEE 802.15.4, Wi-Fi 6, Zigbee
Frequency Range	699 → 6000 Mhz
Connector Type	SMA Male
Gain	0 → 5dBi
Internal/External	External
Antenna Physical Form	Whip
Antenna Mounting Type	Wall/Pole, Screw, Panel Mount, Connector
Series	Oscar 40
Lead Length	5m
Antenna Directivity	Omnidirectional
Antenna Internal Construction	Low Profile, Monopole
Includes Lead	Yes
Connector Gender	Male
