Microchip Technology PIC24EP512GU814-I/PL, 16bit PIC Microcontroller, 60MHz, 536 kB Flash, 144-Pin LQFP

  • RS-artikelnummer 177-3575
  • Tillv. art.nr PIC24EP512GU814-I/PL
  • Tillverkare / varumärke Microchip
Datablad
Lagstiftning och ursprungsland
RoHS-Försäkran
COO (Country of Origin): US
Produktdetaljer

The PIC24E general purpose MCUs feature the highest speed 70 MIPS core with excellent performance and code density. It offers superior ADC performance, CTMU, Op Amps and Peripheral Trigger Generator (PTG) for high-end general purpose applications.

Operating Conditions:
3.0V to 3.6V, -40ºC to +85ºC, DC to 70 MIPS
3.0V to 3.6V, -40ºC to +125ºC, DC to 60 MIPS
PIC24E MCU Core:
Modified Harvard Architecture
C Compiler Optimized Instruction Set
16-bit Wide Data Path
24-bit Wide Instructions
16x16 Integer Multiply Operations
32/16 and 16/16 Integer Divide Operations
High-Speed PWM:
Up to three PWM pairs with independent timing
Dead time for rising and falling edges
7.14 ns PWM resolution
PWM support for:- Inverters, PFC, Lighting- BLDC, PMSM, ACIM, SRM
Programmable Fault inputs
Flexible trigger configurations for ADC conversions
Advanced Analog Features:
ADC module:- Configurable as 10-bit, 1.1 Msps with four S&H or12-bit, 500 ksps with one S&H

Specifikationer
Attribute Value
Family Name PIC24E
Package Type LQFP
Mounting Type Surface Mount
Pin Count 144
Device Core PIC
Data Bus Width 16bit
Program Memory Size 536 kB
Maximum Frequency 60MHz
RAM Size 52 kB
USB Channels 1
Number of PWM Units 1
ADC Channels 32
Number of SPI Channels 4
Typical Operating Supply Voltage 3.6 (Maximum) V
Number of Timers 2
Timer Resolution 16 bit, 32 bit
Height 1.45mm
ADCs 1 (32 x 10 bit), 1 (32 x 12 bit)
Length 20mm
Number of UART Channels 4
Automotive Standard AEC-Q100
Maximum Operating Temperature +85 °C
Program Memory Type Flash
Number of ADC Units 2
Number of CAN Channels 2
Pulse Width Modulation 1 (16 Channel)
Number of I2C Channels 2
Dimensions 20 x 20 x 1.45mm
Minimum Operating Temperature -40 °C
PWM Channels 16
Width 20mm
ADC Resolution 10 bit, 12 bit
60 I lager för leverans inom 1 arbetsdagar
Pris (ex. moms) Each (In a Tray of 60)
82,527 kr
(exkl. moms)
103,159 kr
(inkl. moms)
Enheter
Per unit
Per Tray*
60 +
82,527 kr
4 951,62 kr
