Alpha Wire Premium Series Red 0.75 mm² Hook Up Wire, 18 AWG, 16/0.25 mm, 30m, PVC Insulation, 3055 RD005

The Alpha Wire PVC Single Core hook-up wire contains a stranded tinner copper 18 AWG wire covered in a green and yellow PVC shield, allowing it to be able to operate in temperatures -40ºC all the way up 105ºC. The wire also has ability to withstand wear and abrasion and has high resistance to substances (oil, solvents and chemicals.) The component is in accordance with UL 1007 and VW-1, as well as CSA TR64.

Connect your equipment and machinery to power supply units with this hook-up wire from Belden's Alpha Wire range. The component's tinned copper conductors withstand corrosion to provide a stable connection for reliable, long-term use. A PVC outer sheath insulates the wire, protecting you from electric shocks. As this material also offers resistance to impacts and abrasion, you can use the product in harsh environments. This wire comes on a reel, which means it's easy to handle and you can simply cut what you need for the job at hand.

• Long cable length so you get an ample supply for several jobs
• Wide operating temperature range of -40°C to +105°C, so suitable for industrial use
• Colour-coded insulation for easy identification
• Compact outer diameter of 2.01mm for space efficiency in small enclosures
• Voltage rating of 300V for use in low-voltage applications

• Control cabinets
• Specialised machine tools
• High temperature ovens

This hook-up wire has a maximum bend radius of 10 times its cable diameter. This means it's a practical choice when you need to wire around corners.
