Aim-TTi TGF4082 Function Generator, 1μHz Min, 80MHz Max, FM Modulation, Variable Sweep - With RS Calibration
- RS-artikelnummer:
- 181-3546
- Tillv. art.nr:
- TGF4082
- Tillverkare / varumärke:
- Aim-TTi
2 I lager för leverans inom 3-5 arbetsdagar
Totalt pris (1 Enheter)
12 588,00 kr
(exkl. moms)
15 735,00 kr
(inkl. moms)
Nästa dag-leverans inte möjlig
| Enheter | Per unit |
| 1 + | 12 588,00 kr |
- RS-artikelnummer:
- 181-3546
- Tillv. art.nr:
- TGF4082
- Tillverkare / varumärke:
- Aim-TTi
- COO (Country of Origin):
- GB
Aim-TTi TGF4000 Series Function Generator, Digital Frequency, FM Modulation - TGF4082
This dual-channel function generator provides a frequency range up to 40MHz, offering high-quality signal generation for various applications.
Features & Benefits
• 40MHz frequency range allowing for versatile waveform generation
• Dual-channel output for independent or linked operation
• High resolution pulse generator with up to 100MHz
• 16-bit arbitrary waveforms at 800MSa/s for precise control
• Wideband noise generator for comprehensive modulation options
• Comprehensive built-in waveforms and modulation types for diverse applications
• Remote control via USB, GPIB, and LAN interfaces for ease of use
• Dual-channel output for independent or linked operation
• High resolution pulse generator with up to 100MHz
• 16-bit arbitrary waveforms at 800MSa/s for precise control
• Wideband noise generator for comprehensive modulation options
• Comprehensive built-in waveforms and modulation types for diverse applications
• Remote control via USB, GPIB, and LAN interfaces for ease of use
Applications
• Digital Amplitude and Offset control for precise signal generation
• Wide frequency range suitable for research and development in electronics
• Ideal for use in laboratory settings for testing and calibration
• Suitable for educational purposes in electronics and engineering courses
• Wide frequency range suitable for research and development in electronics
• Ideal for use in laboratory settings for testing and calibration
• Suitable for educational purposes in electronics and engineering courses
Can it provide high-resolution pulse generation?
Yes, it offers a high-resolution pulse generator up to 100MHz for detailed pulse waveform generation.
Will it allow remote control via different interfaces?
Yes, this function generator supports remote control through USB, GPIB, and LAN interfaces for enhanced usability.
Is the frequency range suitable for educational purposes?
The 40MHz frequency range of the TGF4082 makes it ideal for educational settings offering diverse application scenarios.
Attribute | Value |
|---|---|
| Series | TGF4000 |
| Model Number | TGF4082 |
| Calibrated | RSCAL |
| Digital Frequency | Yes |
| Minimum Frequency Range Sinewave | 1µHz |
| Maximum Frequency Range Sinewave | 80MHz |
| Maximum Frequency Range Square Pulse and Arbitrary Waveform | 25 (Square & Pulse) MHz, 40 (Arbitrary) MHz |
| Minimum Frequency Range Square Pulse and Arbitrary Waveform | 1 μHz |
| Minimum Frequency Range Triangle/Saw | 1µHz |
| Maximum Frequency Range Triangle/Saw | 5MHz |
| Digital Amplitude and Offset | Yes |
| Internal Linear and Log Sweep | Yes |
| Variable Sweep | Yes |
| Internal and External Amplitude Modulation | Yes |
| FM Modulation | Yes |
| Time Base Accuracy | <±1 (Initial Settling Error) ppm, <±1(Oscillator Aging Rate) ppm, <1(Temperature Range) ppm |
| Input Impedance | 10 kΩ |
| Width | 295mm |
| Height | 97mm |
| Dimensions | 250 x 295 x 97mm |
| Minimum Operating Temperature | +5°C |
| Frequency Range Square Pulse and Arbitrary Waveform | 1 μHz → 25 MHz (Square & Pulse), 40 (Arbitrary) MHz |
| Interface Type | GPIB, LAN, USB |
| Maximum Operating Temperature | +40°C |
| Weight | 3.1kg |
| TTL Output Level | 10V Pk-Pk |
| Length | 250mm |
| Output Impedance | 50Ω |
