Vishay MKP1848C DC-Link Polypropylene Film Capacitor, 1kV dc, ±5%, 100μF, Through Hole
- RS-artikelnummer:
- 825-1477P
- Tillv. art.nr:
- MKP1848C71010JY5
- Tillverkare / varumärke:
- Vishay
7 I lager för avsändande samma dag
Pris (ex. moms) Varje (levereras i en påse)
495,61 kr
(exkl. moms)
619,51 kr
(inkl. moms)
Enheter | Per enhet |
|---|---|
| 5 - 9 | 495,61 kr |
| 10 - 24 | 469,55 kr |
| 25 - 49 | 443,49 kr |
| 50 + | 417,43 kr |
- RS-artikelnummer:
- 825-1477P
- Tillv. art.nr:
- MKP1848C71010JY5
- Tillverkare / varumärke:
- Vishay
Datablad
Lagstiftning och ursprungsland
Produktdetaljer
MKP 1848C Series
MKP 1848C Series is a high density DC-link capacitor
High ripple current capability, low ESR and low ESL
Applications include: Renewable energies inverters UPS, Battery chargers and Motor drives
High ripple current capability, low ESR and low ESL
Applications include: Renewable energies inverters UPS, Battery chargers and Motor drives
Specifikationer
Attribute | Value |
|---|---|
| Capacitance | 100µF |
| Voltage | 1kV dc |
| Mounting Type | Through Hole |
| Tolerance | ±5% |
| Series | MKP1848C DC-Link |
| Lead Pitch | 52.5mm |
| Length | 57.5mm |
| Depth | 70mm |
| Height | 65mm |
| Equivalent Series Resistance | 3.5mΩ |
| Dimensions | 57.5 x 70 x 65mm |
| Dielectric | Polypropylene |
| Terminal Type | Through Hole |
| Maximum Operating Temperature | +85°C |
| Lead Diameter | 1.2mm |
