Winslow, W3100 2.54mm Pitch Vertical 18 Way, Through Hole Stamped Pin Open Frame IC Dip Socket, 10A
- RS-artikelnummer:
- 402-787
- Tillv. art.nr:
- W3118TRC
- Tillverkare / varumärke:
- Winslow
3750 I lager för avsändande samma dag
Lagt till varukorgen
Pris (ex. moms) Var (i ett paket med 50)
2,459 kr
(exkl. moms)
3,074 kr
(inkl. moms)
| Enheter | Per unit | Per Pack* |
| 50 - 450 | 2,459 kr | 122,95 kr |
| 500 - 1200 | 2,077 kr | 103,85 kr |
| 1250 - 2450 | 1,696 kr | 84,80 kr |
| 2500 - 4950 | 1,312 kr | 65,60 kr |
| 5000 + | 0,932 kr | 46,60 kr |
- RS-artikelnummer:
- 402-787
- Tillv. art.nr:
- W3118TRC
- Tillverkare / varumärke:
- Winslow
Datablad
Lagstiftning och ursprungsland
- COO (Country of Origin):
- TW
Produktdetaljer
Winslow Adaptics W3100 Series DIL Stamped IC Sockets
W3100 series DIL stamped IC sockets with a low profile end and side stackable design making them ideal for use in high density circuit layouts. These W3100 DIL IC sockets have tin-plated dual wipe contacts that offer maximum contact retention at minimum cost and a large lead-in area provides easy package insertion. Other features of these W3100 series stamped IC sockets include overstress protection, a 35 degree angled contact to prevent the IC leg from going behind the contact during insertion and an operating temperature range of -65°C → +150°C
Specifikationer
Attribute | Value |
|---|---|
| Number of Contacts | 18 |
| Mounting Type | Through Hole |
| Pin Type | Stamped |
| Pitch | 2.54mm |
| Row Width | 7.62mm |
| Frame Type | Open Frame |
| Termination Method | Solder |
| Contact Plating | Tin |
| Current Rating | 10A |
| Orientation | Vertical |
| Length | 22.73mm |
| Width | 4.5mm |
| Depth | 10.14mm |
| Dimensions | 22.73 x 4.5 x 10.14mm |
| Minimum Operating Temperature | -65°C |
| Housing Material | PBT |
| Maximum Operating Temperature | +150°C |
| Contact Material | Phosphor Bronze |
| Series | W3100 |
