MEAN WELL DC-DC Converter, 12V dc/ 60A Output, 72 → 144 V dc Input, 1000W, Rack Mount, +60°C Max Temp -20°C Min
- RS-artikelnummer:
- 678-3675
- Tillv. art.nr:
- SD-1000H-12
- Tillverkare / varumärke:
- MEAN WELL
2 I lager för avsändande samma dag
Lagt till varukorgen
Pris (ex. moms) Varje
4 887,80 kr
(exkl. moms)
6 109,75 kr
(inkl. moms)
Enheter | Per unit |
1 - 4 | 4 887,80 kr |
5 - 9 | 4 741,18 kr |
10 - 24 | 4 594,58 kr |
25 - 49 | 4 447,88 kr |
50 + | 4 301,28 kr |
- RS-artikelnummer:
- 678-3675
- Tillv. art.nr:
- SD-1000H-12
- Tillverkare / varumärke:
- MEAN WELL
Lagstiftning och ursprungsland
- COO (Country of Origin):
- TW
Produktdetaljer
SD-1000 Series Single Output Enclosed Regulated Isolated DC-DC Converter
High reliability
1U low profile - 41mm
High power density - 10.7W/inch³
Ultra-wide 4:1 input voltage range
Regulated outputs
12V, 0.25A auxiliary output
Easy installation - screw terminals
Adjustable output voltage
EMC meets EN 55022 Class B
Forced air cooling by built-in dual fans with speed control
Remote ON/OFF control
Remote sense
LED power-on indicator
Short circuit, over-load, over-voltage and over-temperature protection
2kV input / output isolation
1U low profile - 41mm
High power density - 10.7W/inch³
Ultra-wide 4:1 input voltage range
Regulated outputs
12V, 0.25A auxiliary output
Easy installation - screw terminals
Adjustable output voltage
EMC meets EN 55022 Class B
Forced air cooling by built-in dual fans with speed control
Remote ON/OFF control
Remote sense
LED power-on indicator
Short circuit, over-load, over-voltage and over-temperature protection
2kV input / output isolation
Note
De-rating above 50°C.
MTBF to MIL-HDBK-217F (25°C).
MTBF to MIL-HDBK-217F (25°C).
Standards
IEC 60950-1
Approvals
CB, TUV
Specifikationer
Attribute | Value |
---|---|
Output Voltage | 12V dc |
Input Voltage Range | 72 → 144 V dc |
Power Rating | 1000W |
Input Voltage Nominal | 96 V dc |
Output Current | 60A |
Mounting Type | Rack Mount |
Isolated | Yes |
Number of Outputs | 1 |
Output Voltage Adjustment Range | 11 → 15V |
Isolation Voltage | 2kV ac |
Depth | 41mm |
Width | 127mm |
Length | 295mm |
Load Regulation | ±0.5% |
Minimum Temperature | -20°C |
Standards Met | 3, 4, 5, 6, 8, EN 55022 (CISPR22) Class B, EN 61000-4-2, ENV 50204, Heavy Industry Level Criteria A |
Efficiency | 85% |
Maximum Temperature | +60°C |
