STMicroelectronics ULQ2803A Octal NPN Darlington Transistor, 500 mA 50 V HFE:1000 @ 350 mA @ 2 V, 18-Pin PDIP

RS-artikelnummer:: 168-8906
Tillv. art.nr:: ULQ2803A
Tillverkare / varumärke:: STMicroelectronics

STMicroelectronics ULQ2803A Octal NPN Darlington Transistor, 500 mA 50 V HFE:1000 @ 350 mA @ 2 V, 18-Pin PDIP

Tillfälligt slut i lager – restorder för leverans 2024-05-08

Lagt till varukorgen

Pris (ex. moms) Var (i ett rör med 20)

24,188 kr

(exkl. moms)

30,235 kr

(inkl. moms)

Enheter	Per unit	Per Tube*
20 - 20	24,188 kr	483,76 kr
40 - 80	22,729 kr	454,58 kr
100 +	21,764 kr	435,28 kr

RS-artikelnummer:: 168-8906
Tillv. art.nr:: ULQ2803A
Tillverkare / varumärke:: STMicroelectronics

Datablad

Lagstiftning och ursprungsland

COO (Country of Origin):: CH

Produktdetaljer

Darlington Transistor Arrays, STMicroelectronics

Darlington transistor power drivers are high-voltage, high-current switch arrays containing multiple open-collector Darlington pairs and integral suppression diodes for inductive loads. The high current rating of each output is 500 mA or higher. The inputs are pinned opposite the outputs in the IC package to simplify the application board layout. The interface is standard logic level for TTL or CMOS.

Darlington Transistor Drivers

Specifikationer

Attribute	Value
Transistor Type	NPN
Maximum Continuous Collector Current	500 mA
Maximum Collector Emitter Voltage	50 V
Maximum Emitter Base Voltage	30 V
Package Type	PDIP
Mounting Type	Through Hole
Pin Count	18
Transistor Configuration	Common Emitter
Number of Elements per Chip	8
Minimum DC Current Gain	1000 @ 350 mA @ 2 V
Maximum Collector Base Voltage	30 V
Maximum Collector Emitter Saturation Voltage	1.6 V
Maximum Power Dissipation	2.25 W
Height	3.67mm
Dimensions	23.24 x 7.1 x 3.67mm
Maximum Operating Temperature	+85 °C
Length	23.24mm
Base Current	25mA
Minimum Operating Temperature	-40 °C
Width	7.1mm
