Vishay Bridge Rectifier, 600 V 50 A, 4-Pin Single
- RS-artikelnummer:
- 710-2881
- Distrelec artikelnummer:
- 304-44-139
- Tillv. art.nr:
- DF06S-E3/77
- Tillverkare / varumärke:
- Vishay
Mängdrabatt möjlig
Antal (1 förpackning med 20 enheter)*
99,68 kr
(exkl. moms)
124,60 kr
(inkl. moms)
Lägg till 120 enheter för att få fri frakt
I lager
- 280 enhet(er) är redo att levereras
- Plus 20 enhet(er) är redo att levereras från en annan plats
- Dessutom levereras 4 580 enhet(er) från den 12 februari 2026
Behöver du mer? Ange den kvantitet du behöver och klicka på "Kontrollera leveransdatum"
Enheter | Per enhet | Per förpackning* |
|---|---|---|
| 20 - 180 | 4,984 kr | 99,68 kr |
| 200 - 480 | 3,836 kr | 76,72 kr |
| 500 - 980 | 3,237 kr | 64,74 kr |
| 1000 - 1980 | 3,035 kr | 60,70 kr |
| 2000 + | 2,75 kr | 55,00 kr |
*vägledande pris
- RS-artikelnummer:
- 710-2881
- Distrelec artikelnummer:
- 304-44-139
- Tillv. art.nr:
- DF06S-E3/77
- Tillverkare / varumärke:
- Vishay
Specifikationer
Datablad
Lagstiftning och ursprungsland
Produktdetaljer
Hitta liknande produkter genom att välja ett eller flera attribut.
Välj alla | Attribut | Värde |
|---|---|---|
| Brand | Vishay | |
| Product Type | Bridge Rectifier | |
| Peak Reverse Repetitive Voltage Vrrm | 600V | |
| Mount Type | Surface | |
| Number of Phases | 1 | |
| Package Type | DFS | |
| Pin Count | 4 | |
| Configuration | Single | |
| Maximum Operating Temperature | 150°C | |
| Forward Current If | 1A | |
| Minimum Operating Temperature | -55°C | |
| Peak Non-Repetitive Forward Surge Current Ifsm | 50A | |
| Peak Forward Voltage Vf | 1.1V | |
| Standards/Approvals | No | |
| Length | 8.51mm | |
| Height | 3.3mm | |
| Peak Reverse Current Ir | 5μA | |
| Width | 6.5 mm | |
| Series | DF | |
| Automotive Standard | No | |
| Välj alla | ||
|---|---|---|
Brand Vishay | ||
Product Type Bridge Rectifier | ||
Peak Reverse Repetitive Voltage Vrrm 600V | ||
Mount Type Surface | ||
Number of Phases 1 | ||
Package Type DFS | ||
Pin Count 4 | ||
Configuration Single | ||
Maximum Operating Temperature 150°C | ||
Forward Current If 1A | ||
Minimum Operating Temperature -55°C | ||
Peak Non-Repetitive Forward Surge Current Ifsm 50A | ||
Peak Forward Voltage Vf 1.1V | ||
Standards/Approvals No | ||
Length 8.51mm | ||
Height 3.3mm | ||
Peak Reverse Current Ir 5μA | ||
Width 6.5 mm | ||
Series DF | ||
Automotive Standard No | ||
- COO (Country of Origin):
- CN
Bridge Rectifiers for PCB Surface Mount, DFxxS Series, Vishay Semiconductor
High surge current capability
Low DC reverse current
Ideal for automated placement
Printed Circuit Board (PCB) reflow soldering
Bridge Rectifiers - Vishay Semiconductor
The Bridge Rectifier converts an Alternating Current (AC) input into a Direct Current (DC) output for full-wave rectification applications. The diode arrangement provides the same polarity of output for either polarity of input. A three-phase full-wave rectifier is an arrangement of six diodes in a bridge circuit configuration. The packages are designed for minimal size, highest reliability and maximum thermal performance.
Approvals
UL file E54214
