MAX9860ETG+T, Audio Codec IC, 1 (DAC), 2 (ADC)-Channel, 24-Pin TQFN

RS-artikelnummer:: 191-3284
Tillv. art.nr:: MAX9860ETG+T
Tillverkare / varumärke:: Maxim Integrated

MAX9860ETG+T, Audio Codec IC, 1 (DAC), 2 (ADC)-Channel, 24-Pin TQFN

Se kategorien

2500 I lager för avsändande samma dag

Lagt till varukorgen

Se varukorgen

Pris (ex. moms) Var (i en rulle med 2500)

20,248 kr

(exkl. moms)

25,31 kr

(inkl. moms)

Enheter	Per unit	Per Reel*
2500 +	20,248 kr	50 620,00 kr

RS-artikelnummer:: 191-3284
Tillv. art.nr:: MAX9860ETG+T
Tillverkare / varumärke:: Maxim Integrated

Datablad

Datasheet - MAX9860ETG+T

Lagstiftning och ursprungsland

Produktdetaljer

1.8V Single-Supply Operation
Digital Highpass Elliptical Filters with Notch for 217Hz (GSM)
Mono 30mW BTL Headphone Amplifier
Dual Low-Noise Microphone Inputs
Automatic Microphone Gain Control and Noise Gate
90dB DAC DR (fS = 48kHz)
81dB ADC DR (fS = 48kHz)
Supports Master Clock Frequencies from 10MHz to 60MHz
Supports Sample Rates from 8kHz to 48kHz
Flexible Digital Audio Interface
Clickless/Popless Operation
2-Wire, I²C-Compatible Control Interface
Available in 24-Pin, Thin QFN, 4mm x 4mm x 0.8mm Package
Applications
Audio Accessories
Audio Headsets
Mobile Phones
Portable Navigation Device
Smart Phones
VoIP Phones

Specifikationer

Attribute	Value
IC Type	Audio Codec IC
Number of Channels	1 (DAC), 2 (ADC)
Power Supply Type	Single
Mounting Type	Surface Mount
Package Type	TQFN
Pin Count	24
Number of DACs	1
Typical Operating Supply Voltage	1.8 V
Sampling Rate	8 to 48kHz
Dimensions	4.1 x 4.1 x 0.75mm
ADC/DAC Resolution	16bit
Number of ADCs	2
Codec Type	Mono Audio
Maximum Operating Temperature	+85 °C
Minimum Operating Temperature	-40 °C
