Surface Mount Audio Transformer
- RS-artikelnummer:
- 168-3326
- Tillv. art.nr:
- 749196507
- Tillverkare / varumärke:
- Wurth Elektronik
Tillfälligt slut i lager – restorder för leverans 2024-10-24
Lagt till varukorgen
Pris (ex. moms) Varje
106,13 kr
(exkl. moms)
132,66 kr
(inkl. moms)
| Enheter | Per unit |
| 1 - 4 | 106,13 kr |
| 5 - 9 | 98,81 kr |
| 10 - 24 | 92,38 kr |
| 25 - 49 | 88,17 kr |
| 50 + | 78,63 kr |
- RS-artikelnummer:
- 168-3326
- Tillv. art.nr:
- 749196507
- Tillverkare / varumärke:
- Wurth Elektronik
Datablad
Lagstiftning och ursprungsland
- COO (Country of Origin):
- PH
Produktdetaljer
Transformer with 6 identical windings
4 sizes with 5 different lengths of air gap each
Isolation voltage up to 1.5 kVAC
Low leakage inductance
Operating temperature: -40 ºC to +125 ºC
By using different circuits more than 375 transformer solutions and about 125 choke solutions possible. Consequently, quick prototyping possibilities
EFD size parts provide Basic insulation for a working voltage of 250VRMS when they are connected appropriate
Flyback converters
Forward converters
Push-pull converters
Step-up/step-down converters
SEPIC
4 sizes with 5 different lengths of air gap each
Isolation voltage up to 1.5 kVAC
Low leakage inductance
Operating temperature: -40 ºC to +125 ºC
By using different circuits more than 375 transformer solutions and about 125 choke solutions possible. Consequently, quick prototyping possibilities
EFD size parts provide Basic insulation for a working voltage of 250VRMS when they are connected appropriate
Flyback converters
Forward converters
Push-pull converters
Step-up/step-down converters
SEPIC
Specifikationer
Attribute | Value |
|---|---|
| Primary DC Resistance | 36mΩ |
| Current Rating | 2.3A |
| Dimensions | 21.5 x 21 x 12mm |
| Mounting Type | Surface Mount |
| Termination Type | Solder |
| Depth | 12mm |
| Length | 21.5mm |
| Width | 21mm |
| Construction | Enclosed |
| Maximum Temperature | +125°C |
| Turns Ratio | 1:1:1:1:1:1 |
| Minimum Temperature | -40°C |
