Vishay 2200μF Aluminium Electrolytic Capacitor 100V dc, Snap-In - MAL225639222E3
- RS-artikelnummer:
- 173-0642
- Tillv. art.nr:
- MAL225639222E3
- Tillverkare / varumärke:
- Vishay
Tillfälligt slut i lager – restorder för leverans 2024-07-19
Lagt till varukorgen
Pris (ex. moms) Var (i en låda med 66)
65,76 kr
(exkl. moms)
82,20 kr
(inkl. moms)
| Enheter | Per unit | Per Box* |
| 66 - 66 | 65,76 kr | 4 340,16 kr |
| 132 - 264 | 59,184 kr | 3 906,144 kr |
| 330 + | 55,895 kr | 3 689,07 kr |
- RS-artikelnummer:
- 173-0642
- Tillv. art.nr:
- MAL225639222E3
- Tillverkare / varumärke:
- Vishay
Lagstiftning och ursprungsland
- COO (Country of Origin):
- CN
Produktdetaljer
256 Series
MAL256 Series Polarized Aluminium Electrolytic Capacitors, non-solid electrolyte
Pressure relief on the top of the Aluminium case
PET insulation sleeve
Pressure relief on the top of the Aluminium case
PET insulation sleeve
Useful life of 2000h at +105°C and greater than 5000h at +85°C
Voltage range from 16V to 100V
Applications in General purpose, industrial; Standard and Switched Mode Power Supplies; Audio systems; DC/DC converters; Telecom; Smoothing and Filtering
Voltage range from 16V to 100V
Applications in General purpose, industrial; Standard and Switched Mode Power Supplies; Audio systems; DC/DC converters; Telecom; Smoothing and Filtering
Specifikationer
Attribute | Value |
|---|---|
| Capacitance | 2200µF |
| Voltage | 100V dc |
| Mounting Type | Snap-In |
| Technology | Aluminium Electrolytic |
| Dimensions | 26 (Dia.) x 42mm |
| Height | 42mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 26mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 10mm |
| Lifetime | 2000h |
| Leakage Current | 1.41 mA |
| Series | 256 |
| Ripple Current | 2.15A |
| Tolerance | ±20% |
| Equivalent Series Resistance | 121mΩ |
