Pneumatic Filters

Pneumatic filters keep pneumatic systems working correctly by removing contaminants, like water and oil vapour, from a compressed airstream. Some use a 'media' to trap particles and let only air pass through, while others use a type of membrane that only allows air to pass through. Pneumatic filters are often used alongside pneumatic air lubricators.

Pneumatic filters are considered to be an essential component that can prevent pneumatic equipment from failing. The amount of maintenance needed for these filters depends on how much debris is being filtered. Sometimes there might be a drop in pressure and this usually is an indicator that the pneumatic filter needs to be cleaned. Parts of the filter that should not be maintained are the service indictor and the automatic or manual drain.

RS Components have a great range of pneumatic equipment including filtration components like these filters to help remove contaminants. We stock pneumatic filters in a wide range of configurations including various filtration sizes, port connections and drain types including automatic and manual to meet many different filtration applications.

What are pneumatic filters used for?

Pneumatic filters are used in a diverse range of environments and industries such as medicine, analytical instrumentation, food processing, marine and aviation, manufacturing and food and beverage packaging. In order for pneumatic machinery to work effectively and efficiency ,compressed air must be clean and free of water and other particles. By using pneumatic filters they remove contamination and increase component life.

Primary filters

Primary filters protect pneumatic devices from damage that could be caused by contaminants such as dirt particles, small water droplets or aerosols. These primary filters will remove particles as small as five micrometres from the air.

Secondary filters

Secondary filters can trap particles as small as 50 nanometres. They can remove fumes, odours, moisture, oils and other very small particles from the air stream.

What type of pneumatic filters are available?

  • Pneumatic Water Separators - helps remove water
  • Pneumatic Particulate Filters - traps dirt and particles
  • Pneumatic Coalescing Filter - for removing water, rust, and oil from an air supply
  • Absorbing Filter -removes oil from compressed air streams

...
Read more Read less

Filter

Visar 1 - 20 av 350 produkter
Resultat per sida
Beskrivning Pris Manufacturer Series Filtration Size Drain Type Port Connection Maximum Flow Rate Typical Flow Rate Minimum Operating Pressure Maximum Operating Pressure Maximum Operating Temperature Port Connection Thread Standard Minimum Operating Temperature Port Connection Thread Size Bowl Material Filter Type
RS-artikelnummer 867-5781
Tillv. art.nrP32FB14ESAN
VarumärkeParker
722,37 kr
Each
Enheter
P32 5µm Automatic G 1/2 23SCFM - 150psi 250 psi +65.5°C G -25°C 1/2 in Metal Air Filter
RS-artikelnummer 783-1785
Tillv. art.nrAF30-F03-A
VarumärkeSMC
240,31 kr
Each
Enheter
AF 5µm Manual G 3/8 - - - 1 MPa, 1.5 MPa +60°C G -5°C 3/8 in - -
RS-artikelnummer 125-3543
Tillv. art.nrG652ABJP4JA000N
VarumärkeEMERSON – ASCO
472,20 kr
Each
Enheter
652 25µ Automatic, Manual, Semi Automatic G 1/2 - 129.5 SCFM, 3700 L/min - 16 bar +50°C G -20°C 1/2 in Polycarbonate Air Filter
RS-artikelnummer 867-5756
Tillv. art.nrP32FB13ASMN
VarumärkeParker
750,62 kr
Each
Enheter
P32 - Manual G 3/8 23SCFM - 150psi 250 psi +65.5°C G -25°C 3/8 in Metal Air Filter
RS-artikelnummer 398-9108
Tillv. art.nrF07-200-A3TG
VarumärkeNorgren
383,90 kr
Each
Enheter
F07 40µm Automatic G 1/4 - 11.5L/s - 10 bar +50°C G -34°C 1/4 in - -
RS-artikelnummer 867-5766
Tillv. art.nrP32FB13ESMN
VarumärkeParker
431,17 kr
Each
Enheter
P32 5µm Manual G 3/8 23SCFM - 150psi 250 psi +65.5°C G -25°C 3/8 in Metal Air Filter
RS-artikelnummer 867-5762
Tillv. art.nrP32FB13ESAN
VarumärkeParker
722,37 kr
Each
Enheter
P32 5µm Automatic G 3/8 23SCFM - 150psi 250 psi +65.5°C G -25°C 3/8 in Metal Air Filter
RS-artikelnummer 867-5778
Tillv. art.nrP32FB14DSAN
VarumärkeParker
1 090,29 kr
Each
Enheter
P32 0.01µ Automatic G 1/2 23SCFM - 150psi 250 psi +65.5°C G -25°C 1/2 in Metal Air Filter
RS-artikelnummer 783-1725
Tillv. art.nrAF20-F02B-A
VarumärkeSMC
218,40 kr
Each
Enheter
AF 5µm Manual G 1/4 - - - 1 MPa, 1.5 MPa +60°C G -5°C 1/4 in - -
RS-artikelnummer 783-1738
Tillv. art.nrAF20-F02C-A
VarumärkeSMC
370,25 kr
Each
Enheter
AF 5µm Automatic G 1/4 - - 0.1MPa 1 MPa, 1.5 MPa +60°C G -5°C 1/4 in - -
RS-artikelnummer 203-0638
Tillv. art.nrLF-1/2-D-5M-MAXI-A
VarumärkeFesto
1 965,51 kr
Each
Enheter
D 5µm Automatic G 1/2 3700L/min - - - - - - - - -
RS-artikelnummer 238-9153
Tillv. art.nrF64G-NNN-ED2
VarumärkeNorgren
951,26 kr
Each
Enheter
F64G 25µm - - - - - 0.034 bar +50°C - -20°C - - -
RS-artikelnummer 203-0733
Tillv. art.nrLFX-1/2-D-MIDI
VarumärkeFesto
1 173,38 kr
Each
Enheter
D - Manual - 900L/min - - - - - - - - -
RS-artikelnummer 202-3447
Tillv. art.nrMS9-LFM-G-BUV
VarumärkeFesto
4 204,73 kr
Each
Enheter
MS 1µm Automatic - 7000L/min - - - - - - - - -
RS-artikelnummer 203-0639
Tillv. art.nrLF-1/4-D-MINI
VarumärkeFesto
346,64 kr
Each
Enheter
D 40µm Manual G 1/4 1200L/min - - - - - - - - -
RS-artikelnummer 203-0649
Tillv. art.nrLFMA-1/2-D-MIDI
VarumärkeFesto
1 173,38 kr
Each
Enheter
D 0.01µm Manual G 1/2 1120L/min - - - - - - - - -
RS-artikelnummer 202-3323
Tillv. art.nrMS6-LF-1/2-CUV
VarumärkeFesto
1 165,29 kr
Each
Enheter
MS 5µm Automatic G 1/2 3200L/min - - - - - - - - -
RS-artikelnummer 398-9091
Tillv. art.nrF07-100-A3TG
VarumärkeNorgren
383,90 kr
Each
Enheter
F07 40µm Automatic G 1/8 - 9L/s - 10 bar +50°C G -34°C 1/8 in - -
RS-artikelnummer 203-0642
Tillv. art.nrLFMB-3/8-D-MIDI-A
VarumärkeFesto
1 637,54 kr
Each
Enheter
D 1µm Automatic G 3/8 1420L/min - - - - - - - - -
RS-artikelnummer 203-0734
Tillv. art.nrLFX-1/4-D-MIDI
VarumärkeFesto
1 173,38 kr
Each
Enheter
D - Manual - 900L/min - - - - - - - - -
