    Belts & Pulleys

    We offer an extensive range of power transmission belts for any automation or industrial requirement. Find polyurethane belts, twist link, and timing belts as well as wedge and vee friction belts from top brands like Contitech. You can also browse a wide selection of RS Pro branded belts at competitive prices.

    The RS selection of pulleys is designed to perfectly compliment our range of power transmission belts. Within this section, you will find timing belt pulleys and wedge and vee belt pulleys - all RS Pro branded to help you shop for total quality at competitive prices.

    What are Power Transmission Belts?

    Power transmission belts help to drive the transmission by the transfer of power to different parts in the system. This system normally consists of a belt and at least two pulleys to transmit the motion needed, commonly used in the automotive industry.

    Types of Power Transmission Belts

    Power transmission belts come in various types and styles. Popular types include:

    V-belts - have tapered sides and a flat bottom with a trapezoidal cross-section. They work by using the friction between the belt and the pulley to transfer power and have a higher power transmission capacity than flat belts. V-belts are popular due to ease of installation, low cost and are available in a wide range of sizes.

    Synchronous belts - also known as timing belts, have a toothed profile and can be used as an alternative to chains and gears. They overcome belt slippage with teeth that engage with corresponding grooves in the pulley or sprocket boosting drive efficiency above a V-belt. They're used in high-powered transmission applications, such as water pumps, fuel injection pumps and camshafts. They are thin and flexible making them ideal for use where high speed or small pulleys are required. They are less noisy than chain drives and energy-efficient through the life of the belt.

    Flat belts - have a rectangular cross-section that provides a greater level of consistent friction between belts and pulleys. They have low creep and are efficient due to their low bending losses and energy-saving properties and are used in all areas of industrial areas using power transmission for their versatility.

    Belt Diagnostic Kits
    Belt Diagnostic Kits
    Belt Pulleys
    Belt Pulleys
    Drive Belt Gauges
    Drive Belt Gauges
    Laser Alignment Tools
    Laser Alignment Tools
    Link Belts
    Link Belts
    Poly V Belts
    Poly V Belts
    Profile & Round Belts
    Profile & Round Belts
    Timing Belts
    Timing Belts
    V & Wedge Belts
    V & Wedge Belts

    13098 Produkter som visas för Belts & Pulleys

    1 av 655
    OPTIBELT Rubber RB Drive Belt, 559mm Length, 23.4mm Width
    • RS-artikelnummer 216-9894
    • Tillv. art.nr 10 PJ 559 RB
    Varje
    242,87 kr
    OPTIBELT 225 L 050 Timing Belt, 60 Teeth, 571mm Length, 12.7mm Width
    • RS-artikelnummer 204-3193
    • Tillv. art.nr 225 L 050
    Varje
    115,83 kr
    OPTIBELT Drive Belt, belt section A/13, 1150mm Length
    • RS-artikelnummer 204-3043
    • Tillv. art.nr 13 X 1120
    Varje
    138,35 kr
    OPTIBELT 565 5MHP 15 Timing Belt, 113 Teeth, 565mm Length, 15mm Width
    • RS-artikelnummer 217-1774
    • Tillv. art.nr 565 5MHP 15
    Varje
    189,82 kr
    OPTIBELT 700 5MHP 15 Timing Belt, 140 Teeth, 700mm Length, 15mm Width
    • RS-artikelnummer 217-0878
    • Tillv. art.nr 700 5MHP 15
    Varje
    213,12 kr
    OPTIBELT Drive Belt, belt section XPA, 1107mm Length
    • RS-artikelnummer 195-3788
    • Tillv. art.nr XPA 1107 XEP
    Varje
    182,58 kr
    Contitech 10 / T5 / 420 SS Timing Belt, 84 Teeth, 420mm Length, 10mm Width
    • RS-artikelnummer 474-5533
    • Tillv. art.nr 10 / T5 / 420 SS
    Varje
    118,66 kr
    OPTIBELT 25 T5 / 630 Timing Belt, 126 Teeth, 630mm Length, 25mm Width
    • RS-artikelnummer 217-1269
    • Tillv. art.nr 25 T5 / 630
    Varje
    355,65 kr
    OPTIBELT Drive Belt, belt section XPA, 900mm Length
    • RS-artikelnummer 195-3779
    • Tillv. art.nr XPA 900 XEP
    Varje
    143,66 kr
    Contitech 10 / T5 / 355 SS Timing Belt, 71 Teeth, 355mm Length, 10mm Width
    • RS-artikelnummer 474-5476
    • Tillv. art.nr 10 / T5 / 355 SS
    Varje
    120,25 kr
    Contitech 330 H 100 Timing Belt, 66 Teeth, 838.5mm Length, 25.4mm Width
    • RS-artikelnummer 475-0068
    • Tillv. art.nr 330 H 100
    Varje
    203,05 kr
    OPTIBELT Drive Belt, belt section SPZ, 1262mm Length
    • RS-artikelnummer 284-2649
    • Tillv. art.nr SPZ 1262 RP
    Varje
    190,27 kr
    OPTIBELT Drive Belt, belt section SPZ, 1262mm Length
    • RS-artikelnummer 144-8851
    • Tillv. art.nr SPZ 1262
    Varje
    148,07 kr
    Contitech 10 / T5 / 250 SS Timing Belt, 50 Teeth, 250mm Length, 10mm Width
    • RS-artikelnummer 474-5375
    • Tillv. art.nr 10 / T5 / 250 SS
    Varje
    108,93 kr
    Interroll Round Polyurethane Belt
    • RS-artikelnummer 223-6009
    • Tillv. art.nr DL08
    1 påse med 5
    282,01 kr
    Contitech Drive Belt, belt section XPZ, 710mm Length
    • RS-artikelnummer 474-2354
    • Tillv. art.nr XPZ 710
    Varje
    97,06 kr
    OPTIBELT Drive Belt, belt section XPA, 950mm Length
    • RS-artikelnummer 195-3781
    • Tillv. art.nr XPA 950 XEP
    Varje
    158,59 kr
    Contitech 6 / T2.5 / 780 SS Timing Belt, 312 Teeth, 780mm Length, 6mm Width
    • RS-artikelnummer 474-5224
    • Tillv. art.nr 6 / T2.5 / 780 SS
    Varje
    175,22 kr
    RS PRO Timing Belt Pulley, Aluminium 9mm Belt Width x 3mm Pitch, 24 Tooth
    • RS-artikelnummer 146-5388
    Varje
    104,05 kr
    OPTIBELT Drive Belt, belt section 3VX, 250mm Length
    • RS-artikelnummer 283-6944
    • Tillv. art.nr 3VX 250 XEP
    Varje
    83,03 kr
