Distribution Blocks

The primary function of a distribution block is to supply power more efficiently to a series of devices. The secondary function is to isolate short circuit incidents to prevent complete shutdown from occurring. Distribution blocks can handle a range of frequencies and currents. Using distribution blocks requires only one large wire on the input side to link each connected device back to the power source. This eliminates the need for separate wiring of each device.


What are distribution blocks used for?

Distribution blocks are used in various industries:

  • Heating/cooling for operating heaters, cooling systems and ventilation equipment.
  • Power distribution control in the form of voltage transformers, uninterrupted power supply units and distribution cabinets.
  • Solar, wind and turbine as the power supply to distribute energy.
  • Electrical vehicles for charging stations.
  • Electronic automation, including elevators, lifting equipment and conveyor systems.

Types of distribution blocks

The two main types of distribution block are:

  • Bussed (enclosed) blocks, which allow for a larger input cable to be split out into smaller cables for branch circuits.
  • Independent blocks, which enable multiple individual circuits to be routed to a single location as they are not connected to each other.

...
Read more Read less

Filter

Visar 1 - 20 av 901 produkter
Resultat per sida
Beskrivning Pris Number of Ways Termination Method Wire Size Housing Material IP Rating Current Rating Voltage Rating Cable CSA Length Width Height Colour Maximum Operating Temperature Minimum Operating Temperature
RS-artikelnummer 277-9815
Tillv. art.nr0 048 34
VarumärkeLegrand
143,21 kr
Each
Enheter
13 Screw Down - PC IP20 100A 400 V ac 1.5 → 16 mm², 6 → 25 mm² 113mm - - Green +40°C -5°C
RS-artikelnummer 383-1598
Tillv. art.nr1SNA115412R0000
VarumärkeEntrelec
99,88 kr
Each
Enheter
10 Clamp 12 AWG - - 32A 800 V 4mm² 62.5mm - 53mm Grey - -
RS-artikelnummer 413-2331
Tillv. art.nr1SNA179535R2300
VarumärkeEntrelec
495,76 kr
Each
Enheter
11 Screw Down 4 → 2 AWG, 6 AWG, 8 AWG Copper Aluminium Alloy - 125A 600 V 35 inputmm² 128mm 85mm 60mm Grey - -
RS-artikelnummer 383-1582
Tillv. art.nr1SNA115409R2600
VarumärkeEntrelec
50,15 kr
Each
Enheter
5 Clamp 12 AWG - - 32A 800 V 4mm² 32.5mm - 53mm Grey - -
RS-artikelnummer 705-5537
Tillv. art.nr0 048 42
VarumärkeLegrand
110,95 kr
Each
Enheter
8 Screw Down - PC IP20 80A 400 V ac 1.5 → 16mm² 75mm - - Blue +40°C -5°C
RS-artikelnummer 277-2151
Tillv. art.nr0 048 24
VarumärkeLegrand
113,12 kr
Each
Enheter
13 Screw Down - PC - 100A 400 V ac 1.5 → 16 mm², 6 → 25 mm² 113mm - - - +40°C -5°C
RS-artikelnummer 868-0720
VarumärkeRS PRO
208,40 kr
Each
Enheter
- Screw 6 → 16 (With End Sleeve) mm², 10 → 25 (Without End Sleeve) mm² PC - 100A 500 V - 87mm 50mm - - - -
RS-artikelnummer 441-4330
VarumärkeRS PRO
979,28 kr
Each
Enheter
12 Screw Down - PC - 160A 500 V 16 mm², 25 mm², 50 mm² 150mm 84mm 48mm Clear - -
Nytt
RS-artikelnummer 201-4336
Tillv. art.nr3273148
VarumärkePhoenix Contact
42,182 kr
Each (In a Pack of 10)
Enheter
6 Push In 12 AWG Polyamide IP20 24A 690 V 4mm² - - - Violet - -
Nytt
RS-artikelnummer 201-4788
Tillv. art.nr3002794
VarumärkePhoenix Contact
83,281 kr
Each (In a Pack of 20)
Enheter
18 Push In 14 AWG Polyamide IP20 17.5A 450 V 2.5mm² - - - Orange - -
RS-artikelnummer 383-1633
Tillv. art.nr1SNA115338R2500
VarumärkeEntrelec
335,53 kr
Each
Enheter
2 Clamp 6 AWG - - 200A 800 V 10-70 inputmm² 114mm - 56.7mm Grey - -
Nytt
RS-artikelnummer 201-5361
Tillv. art.nr3002903
VarumärkePhoenix Contact
39,47 kr
Each (In a Pack of 20)
Enheter
6 Push In 14 AWG Polyamide IP20 17.5A 450 V 2.5mm² - - - Orange - -
Nytt
RS-artikelnummer 201-4864
Tillv. art.nr3273895
VarumärkePhoenix Contact
90,956 kr
Each (In a Pack of 8)
Enheter
13 Push In 10 AWG Polyamide IP20 32A 450 V 6mm² - - - Pink - -
Nytt
RS-artikelnummer 201-4337
Tillv. art.nr3273182
VarumärkePhoenix Contact
103,105 kr
Each (In a Pack of 8)
Enheter
18 Push In 12 AWG Polyamide IP20 24A 690 V 4mm² - - - Yellow - -
Nytt
RS-artikelnummer 201-4007
Tillv. art.nr3002896
VarumärkePhoenix Contact
39,47 kr
Each (In a Pack of 20)
Enheter
6 Push In 14 AWG Polyamide IP20 17.5A 450 V 2.5mm² - - - Violet - -
Nytt
RS-artikelnummer 201-6235
Tillv. art.nr1047428
VarumärkePhoenix Contact
89,80 kr
Each (In a Pack of 20)
Enheter
19 Push In 14 AWG Polyamide IP20 17.5A 450 V 2.5mm² - - - Pink - -
Nytt
RS-artikelnummer 201-4204
Tillv. art.nr3273742
VarumärkePhoenix Contact
63,835 kr
Each (In a Pack of 8)
Enheter
7 Push In 24 to 10 AWG Polyamide IP20 32A 450 V 0.2 → 6mm² - - - Orange - -
Nytt
RS-artikelnummer 201-4367
Tillv. art.nr3273340
VarumärkePhoenix Contact
40,243 kr
Each (In a Pack of 10)
Enheter
7 Push In 12 AWG Polyamide IP20 24A 450 V 4mm² - - - Brown - -
Nytt
RS-artikelnummer 201-6751
Tillv. art.nr3274042
VarumärkePhoenix Contact
141,513 kr
Each (In a Pack of 8)
Enheter
19 Push In 10 AWG Polyamide IP20 32A 450 V 6mm² - - - Brown - -
Nytt
RS-artikelnummer 201-5758
Tillv. art.nr3273774
VarumärkePhoenix Contact
141,513 kr
Each (In a Pack of 8)
Enheter
19 Push In 24 to 10 AWG Polyamide IP20 32A 800 V 0.2 → 6mm² - - - Yellow - -
