100Ω, Through Hole Trimmer Potentiometer 0.5W Top Adjust Vishay, T7
- RS-artikelnummer:
- 374-6715
- Tillv. art.nr:
- T7YA101MT20
- Tillverkare / varumärke:
- Vishay
65 I lager för avsändande samma dag
Lagt till varukorgen
Pris (ex. moms) Var (i ett paket med 5)
46,068 kr
(exkl. moms)
57,585 kr
(inkl. moms)
| Enheter | Per unit | Per Pack* |
| 5 - 20 | 46,068 kr | 230,34 kr |
| 25 - 45 | 32,25 kr | 161,25 kr |
| 50 - 120 | 29,944 kr | 149,72 kr |
| 125 - 245 | 25,33 kr | 126,65 kr |
| 250 + | 18,41 kr | 92,05 kr |
- RS-artikelnummer:
- 374-6715
- Tillv. art.nr:
- T7YA101MT20
- Tillverkare / varumärke:
- Vishay
Datablad
Lagstiftning och ursprungsland
- COO (Country of Origin):
- CZ
Produktdetaljer
Cermet T7YA Series
Industrial Grade
CECC 41100
Low temperature coefficient and high stability
Clear scale reading for ease of adjustment
IP64 - sealed for dust and PC boards cleaning (not water)
CECC 41100
Low temperature coefficient and high stability
Clear scale reading for ease of adjustment
IP64 - sealed for dust and PC boards cleaning (not water)
Specifikationer
Attribute | Value |
|---|---|
| Maximum Resistance | 100Ω |
| Mounting Type | Through Hole |
| Number of Turns | 1 |
| Orientation | Top Adjust |
| Power Rating | 0.5W |
| Series | T7 |
| Termination Style | Pin |
| Tolerance | ±10% |
| Temperature Coefficient | ±100ppm/°C |
| Shaft Diameter | 4 mm |
| Diameter | 7mm |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +125°C |
