Isabellenhutte 25mΩ, 1206 (3216M) SMD Resistor ±1% 1W - SMK-R025-1.0
- RS-artikelnummer:
- 192-9950
- Tillv. art.nr:
- SMK-R025-1.0
- Tillverkare / varumärke:
- Isabellenhutte
13650 I lager för avsändande samma dag
Lagt till varukorgen
Pris (ex. moms) Var (i en tejp med 10)
16,225 kr
(exkl. moms)
20,281 kr
(inkl. moms)
| Enheter | Per unit | Per Tape* |
| 10 - 90 | 16,225 kr | 162,25 kr |
| 100 - 490 | 14,118 kr | 141,18 kr |
| 500 - 990 | 12,909 kr | 129,09 kr |
| 1000 - 4990 | 11,401 kr | 114,01 kr |
| 5000 + | 8,894 kr | 88,94 kr |
- RS-artikelnummer:
- 192-9950
- Tillv. art.nr:
- SMK-R025-1.0
- Tillverkare / varumärke:
- Isabellenhutte
Datablad
Lagstiftning och ursprungsland
- COO (Country of Origin):
- DE
Produktdetaljer
Two terminal surface mount utilizing ISA-Plan® foil technology. Current sensor for power hybrid applications, Control systems for the automotive market, Power modules, Switch mode power supplies.
1 W power rating at 110 °C
Constant current up to 11 A (8 mOhm)
Excellent long-term stability
High pulse power rating
Mounting: Reflow-, and IR-soldering
Applications
Current sensor for power hybrid applications
Control systems for the automotive market
Power modules
Frequency converters
Switch mode power supplies
Constant current up to 11 A (8 mOhm)
Excellent long-term stability
High pulse power rating
Mounting: Reflow-, and IR-soldering
Applications
Current sensor for power hybrid applications
Control systems for the automotive market
Power modules
Frequency converters
Switch mode power supplies
Specifikationer
Attribute | Value |
|---|---|
| Resistance | 25mΩ |
| Package/Case | 1206 (3216M) |
| Tolerance | ±1% |
| Power Rating | 1W |
| Temperature Coefficient | <50ppm/K |
| Automotive Standard | AEC-Q200 |
| Series | SMK |
| Minimum Operating Temperature | -65°C |
| Maximum Operating Temperature | +170°C |
