Single Pole Double Throw (SPDT) Latching Miniature Push Button Switch, 6.5mm, Panel Mount

  • RS-artikelnummer 253-964
  • Tillv. art.nr 8N1011-Z
  • Tillverkare / varumärke Honeywell
Datablad
Lagstiftning och ursprungsland
RoHS-Försäkran
Produktdetaljer

Honeywell Miniature Push Button Switches

Available in either momentary or alternate actions
Contacts rated at 240Vac 3A, 125Vac 6A
Buttons (not supplied with switch) are available in two sizes, see typically stock no's 339-639 , 339-617
Solder terminals

Specifikationer
Attribute Value
Switch Operation Latching
Mounting Type Panel Mount
Illuminated No
Contact Configuration Single Pole Double Throw (SPDT)
Panel Cut Out Size 6.5 (Dia.)mm
Panel Cut Out Diameter 6.5mm
Actuator Colour Green
Contact Current Rating 3 A @ 250 V ac
Terminal Type Solder
109 I lager för leverans inom 1 arbetsdagar
Pris (ex. moms) Each
132,95 kr
(exkl. moms)
166,19 kr
(inkl. moms)
Enheter
Per unit
1 - 49
132,95 kr
50 - 99
116,59 kr
100 - 249
100,34 kr
250 - 499
83,98 kr
500 +
77,84 kr
