Assemtech Rectangular Reed Switch, NO, , 25mA
- RS-artikelnummer:
- 361-4999
- Tillv. art.nr:
- S1431
- Tillverkare / varumärke:
- Assemtech
75 I lager för avsändande samma dag
Lagt till varukorgen
Pris (ex. moms) Varje
684,52 kr
(exkl. moms)
855,65 kr
(inkl. moms)
| Enheter | Per unit |
| 1 - 5 | 684,52 kr |
| 6 - 11 | 656,51 kr |
| 12 + | 635,83 kr |
- RS-artikelnummer:
- 361-4999
- Tillv. art.nr:
- S1431
- Tillverkare / varumärke:
- Assemtech
Lagstiftning och ursprungsland
- COO (Country of Origin):
- GB
Produktdetaljer
Solid State, Dual O/P, Magnetically Activated
Prewired in a flame retardant Crastine (GFFR) housing
N/O collector output
PNP or NPN output
Bounce free switching up to 10kHz
Sealed to IP67
Cable length 130mm
Dimensions 30 x 20 x 7 mm
N/O collector output
PNP or NPN output
Bounce free switching up to 10kHz
Sealed to IP67
Cable length 130mm
Dimensions 30 x 20 x 7 mm
Note
For suitable magnet see Stock No. 361-5009
Specifikationer
Attribute | Value |
|---|---|
| Switch Shape | Rectangular |
| Normal State Configuration | NO |
| Terminal Type | Wire Lead |
| Maximum Current | 25mA |
| Maximum DC Voltage | 20V |
| Total Length | 330mm |
| Length | 30mm |
| Width | 20mm |
| Dimensions | 30 x 20 x 7mm |
| Minimum Operating Temperature | -30°C |
| Depth | 7mm |
| Maximum Operating Temperature | +70°C |
- RS-artikelnummer:
- 361-4999
- Tillv. art.nr:
- S1431
- Tillverkare / varumärke:
- Assemtech
