Maxim Integrated MAX211CWI+ Line Transceiver, 28-Pin SOIC
- RS-artikelnummer:
- 190-6149
- Tillv. art.nr:
- MAX211CWI+
- Tillverkare / varumärke:
- Maxim Integrated
50 I lager för avsändande samma dag
Lagt till varukorgen
Pris (ex. moms) Var (i ett rör med 25)
81,733 kr
(exkl. moms)
102,166 kr
(inkl. moms)
| Enheter | Per unit | Per Tube* |
| 25 - 25 | 81,733 kr | 2 043,325 kr |
| 50 - 100 | 77,643 kr | 1 941,075 kr |
| 125 + | 73,558 kr | 1 838,95 kr |
- RS-artikelnummer:
- 190-6149
- Tillv. art.nr:
- MAX211CWI+
- Tillverkare / varumärke:
- Maxim Integrated
Datablad
Lagstiftning och ursprungsland
Produktdetaljer
MAX200-MAX209, MAX211, and MAX213 are a family of transceivers with integrated charge pump circuitry for single +5V supply operation.
The drivers maintain the ±5V output signal levels at data rates in excess of 120kbps when loaded.
The MAX211 and MAX213 are available in a 28-pin, wide small-outline (SO) package and a 28-pin shrink small- outline (SSOP) package, which occupies only 40% of the area of the SO. The MAX207 is available in a 24-pin SO package and a 24-pin SSOP. The MAX203 and MAX205 use no external components and are recommended for applications with limited circuit board space.
The drivers maintain the ±5V output signal levels at data rates in excess of 120kbps when loaded.
The MAX211 and MAX213 are available in a 28-pin, wide small-outline (SO) package and a 28-pin shrink small- outline (SSOP) package, which occupies only 40% of the area of the SO. The MAX207 is available in a 24-pin SO package and a 24-pin SSOP. The MAX203 and MAX205 use no external components and are recommended for applications with limited circuit board space.
Specifikationer
Attribute | Value |
|---|---|
| IC Type | Line Transceiver IC |
| Input Type | Single Ended |
| Mounting Type | Surface Mount |
| Number of Transmitters | 4 (RS-232) |
| Package Type | SOIC |
| Pin Count | 28 |
| Dimensions | 18.1 x 7.6 x 2.35mm |
