Murata Power Solutions NMTTLD6S5MC-R7 Line Transceiver, 16-Pin
- RS-artikelnummer:
- 173-7096P
- Tillv. art.nr:
- NMTTLD6S5MC-R7
- Tillverkare / varumärke:
- Murata Power Solutions
Tillfälligt slut i lager – restorder för leverans när den finns i lager
Lagt till varukorgen
Pris (ex. moms) Varje (levereras i en rulle) Quantities below 150 on continuous strip
169,16 kr
(exkl. moms)
211,45 kr
(inkl. moms)
| Enheter | Per unit |
| 1 + | 169,16 kr |
- RS-artikelnummer:
- 173-7096P
- Tillv. art.nr:
- NMTTLD6S5MC-R7
- Tillverkare / varumärke:
- Murata Power Solutions
Datablad
Lagstiftning och ursprungsland
- COO (Country of Origin):
- CN
Produktdetaljer
The NMTTLD6S5MC is a low power electrically isolated TTL data transmission device. No external components are needed as a single 5V supply powers all functions either side of the isolation boundary. NMTTLD655MC also provides a regulated 5V, unregulated 6V and -6V isolated supply’s for system use.
SMD compatible
+6V, -6V unregulated and +5V regulated
TTL signal isolator
2 outgoing 2 incoming data lines
25Mbps data rate
Industrial temperature range -40°C to
+95°C
+6V, -6V unregulated and +5V regulated
TTL signal isolator
2 outgoing 2 incoming data lines
25Mbps data rate
Industrial temperature range -40°C to
+95°C
Specifikationer
Attribute | Value |
|---|---|
| Input Type | Single Ended |
| Mounting Type | Surface Mount |
| Number of Transmitters | 1 |
| Pin Count | 16 |
| Dimensions | 16.89 x 14.7 x 6.56mm |
