Digilent Pmod CAN: CAN 2.0B Controller with Integrated Transceiver Development Kit 410-353
- RS-artikelnummer:
- 172-0815
- Tillv. art.nr:
- 410-353
- Tillverkare / varumärke:
- Digilent
4 I lager för avsändande samma dag
Lagt till varukorgen
Pris (ex. moms) Varje
188,09 kr
(exkl. moms)
235,11 kr
(inkl. moms)
| Enheter | Per unit |
| 1 - 4 | 188,09 kr |
| 5 - 9 | 183,21 kr |
| 10 - 24 | 178,44 kr |
| 25 + | 174,00 kr |
- RS-artikelnummer:
- 172-0815
- Tillv. art.nr:
- 410-353
- Tillverkare / varumärke:
- Digilent
Datablad
Lagstiftning och ursprungsland
Produktdetaljer
Digilent CAN 2.0B Controller Module
The Digilent Pmod CAN 2.0B controller has an integrated transceiver. It utilizes the Microchip MCP25625 to enable CAN communication with a variety of external devices. It enables balanced differential signalling to eliminate most of the electromagnetic field (EMF) and provide high noise immunity within the system. This module is ideal for applications that require high-speed (1 Mb/s), low quiescent current, electromagnetic compatibility and electrostatic discharge.
Features and Benefits:
• 12-pin Pmod connector with an SPI interface
• 2 receive buffers
• 3 transmit buffers with prioritization and abort feature
• 6 filters and 2 masks with optional filtering on the first two data bytes
• Interrupt output pin
• Small PCB size for flexible designs 1.4inx1.8in (3.6cmx4.6cm)
• Standard DB9 connector for a secure connection
• Suitable for 12V and 24V systems as well
• Up to 10MHz SPI clock speed
• 2 receive buffers
• 3 transmit buffers with prioritization and abort feature
• 6 filters and 2 masks with optional filtering on the first two data bytes
• Interrupt output pin
• Small PCB size for flexible designs 1.4inx1.8in (3.6cmx4.6cm)
• Standard DB9 connector for a secure connection
• Suitable for 12V and 24V systems as well
• Up to 10MHz SPI clock speed
Applications:
• Automotive
• Embedded systems
• Embedded systems
Certifications:
• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007
• ISO-11898-1 certified
• ISO-11898-2 certified
• ISO-11898-5 certified
• BS EN 61340-5-1:2007
• ISO-11898-1 certified
• ISO-11898-2 certified
• ISO-11898-5 certified
Specifikationer
Attribute | Value |
|---|---|
| Classification | Add On Board |
| Technology | SPI |
| Kit Classification | Development Kit |
| Kit Name | Pmod CAN: CAN 2.0B Controller with Integrated Transceiver |
