- RS-artikelnummer:
- 167-7335
- Tillv. art.nr:
- BA50BC0FP-E2
- Tillverkare / varumärke:
- ROHM
110 I lager för avsändande samma dag
Inom 5 arbetsdag(ar) (UK lager)
Lagt till varukorgen
Pris (ex. moms) Var (i ett paket med 10)
10,251 kr
(exkl. moms)
12,814 kr
(inkl. moms)
Enheter | Per unit | Per Pack* |
10 - 40 | 10,251 kr | 102,51 kr |
50 - 240 | 9,43 kr | 94,30 kr |
250 + | 8,697 kr | 86,97 kr |
- RS-artikelnummer:
- 167-7335
- Tillv. art.nr:
- BA50BC0FP-E2
- Tillverkare / varumärke:
- ROHM
Lagstiftning och ursprungsland
- COO (Country of Origin):
- JP
Produktdetaljer
ROHM's secondary LDO regulators were designed to maximize device characteristics and provide stable operation through low power consumption, increased miniaturization, and low noise. 1A fixed output types are offered for local power supplies that feature an output voltage accuracy of ±2% with low saturation. A broad lineup is offered in a number of output voltages (variable, 1.5V-10V) and package types (TO252, TO220FP/CP) for compatibility with a wide range of applications, such as TVs, HDDs, PCs, and DVD players. In addition, multiple protection circuits are integrated (i.e. overcurrent, thermal shutdown), providing a high level of reliability.
Maximum current: 1A
Output voltage accuracy: ±1%
Ultra-low saturation with PNP output
Output voltage accuracy: ±1%
Ultra-low saturation with PNP output
Specifikationer
Attribute | Value |
---|---|
Regulator Type | Low Dropout Voltage |
Maximum Output Current | 1A |
Number of Outputs | 1 |
Output Voltage | 5 V |
Line Regulation | 35 mV |
Load Regulation | 75 mV |
Accuracy | ±2% |
Mounting Type | Surface Mount |
Polarity | Positive |
Package Type | TO-252 |
Pin Count | 3 |
Output Type | Fixed |
Dimensions | 6.5 x 5.5 x 2.3mm |
Maximum Input Voltage | 16 V |
Minimum Input Voltage | 3 V |
Minimum Operating Temperature | -40 °C |
Height | 2.3mm |
Maximum Operating Temperature | +105 °C |
Width | 5.5mm |
Length | 6.5mm |
